32
English
Display contents SEG1 SEG2 SEG3 SEG4
K4
long
push
-
Main micom version Year (Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short push 1 Inverter micom version Year(Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short push 2 E2P version Year(Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short push 3 Page 1 - AUTO Page 2 - (SEG1,2 - Indoor : "A","0") (SEG3,4 - Address : ex)00 )
After short push 4 Page 1 - MANU Page 2 - (SEG1,2 - Indoor : "A","0") (SEG3,4 - Address : ex)00 )
❋ Long push K4 (Main micom ver.) short push 1 more (Inv. micom ver.) short push 1 more (E2P. ver.)
7. DIP switch option
AC012/018/024
ON
1234
SW2
AC030/036/042/060
ON
1234 1234
ON
SW507 SW508
f SW2 and SW507 option
On (default) O
Switch 1 --
Switch 2
Disable snow
prevention control
Enable snow
prevention control
Switch 3
Silence mode option
Switch 4
Switch 3 Switch 4 Operation
On On Disable Silence mode
On O Silence mode step 1
O On Silence mode step 2
O O Silence mode step 3
f The compressor frequency limit in the Silence mode can
be set to one of three steps.
The noise level decreases in the order of steps 1, 2, and 3.
f When snow prevention mode is in use, eco mode
(standby mode) will not work.
f SW508 option
On (default) O
Switch 1 Auto Silence mode Manual Silence mode
Switch 2 --
Switch 3 --
Switch 4 --
f In the Auto Silence mode, the air conditioner
automatically enters the silence mode 6 hours after the
outdoor temperature reaches its highest temperature.
In the Manual Silence mode, the air conditioner is
set so that the maximum operation frequency of the
compressor is limited immediately when an external
silence contact signal is received
8. Setting the address manually
f Turn o the air conditioner, press and hold the K2 switch
for a while to enter the Option mode. (Initial value: 00AU)
ࣙ You cannot enter the Option mode when the air
conditioner is running.
f Set the address in SEG3 and SEG4 by pressing the K2
switch shortly.
Option SEG1 SEG2 SEG3 SEG4 Function
Channel
address
00AU
The address is set
automatically.
00 to 15
The address is set
manually. You can set
avalue from 0 to 15.
f Press and hold the K2 switch for a while to save the
address and exit the Option mode. Each segment will
icker for 3 seconds in the current display state. Then if
you need to change the address, reset the system, and
then repeat all steps again. Press and hold the K1 switch
to exit without save.
❋ If you want to restore the setting to factory default,
press and hold the K4 button while you are in the
option setting mode.
ࣙ If you press and hold the K4 button, setting will
be restored to factory default but it doesn't mean
that restored setting is saved.Press and hold
the K2 button. When the segments shows that
tracking mode is in progress, setting will be saved
Testing operations
