Installation Procedure
English
Installation Procedure
đɇΧͱиʪθʀɇɵʪϑΧʪʀѣʀɇϩͱϑ
The power cable is not supplied with air conditioner.
• Select the power supply cable in accordance with relevant local and national regulations.
• Wire size must comply with the applicable local and national code.
• Specifications for local wiring power cord and branch wiring are in compliance with local cord.
Model Outdoor unit Input current (A) Power supply
Indoor unit Outdoor unit Hz
Voltage range (V)
Outdoor unit Indoor unit Total MCA (A) MFA (A)
Rated Min. Max.
AC024TN4PKC
AC024TXADKC
50/60 220 to 240 198 264
20.0 1.5 21.5 21.5 25.0
AC024TN4DKC
20.0 1.5 21.5 21.5 25.0
AC024TNMDKC
20.0 2.3 22.3 22.3 25.0
AC036TN4PKC
AC036TXADKC
24.0 2.0 26.0 26.0 30.0
AC036TN4DKC
24.0 2.0 26.0 26.0 30.0
AC036TNCDKC
24.0 2.5 26.5 26.5 30.0
AC048TN4PKC
AC048TXADKC
32.0 2.0 34.0 34.0 40.0
AC048TN4DKC
32.0 2.0 34.0 34.0 40.0
AC048TNMDKC
32.0 2.5 34.5 34.5 40.0
AC048TNCDKC
32.0 2.5 34.5 34.5 40.0
AC054TNMDKC
AC054TXADKC
32.0 3.5 35.5 35.5 40.0
AC054TNCDKC
32.0 3.0 35.0 35.0 40.0
NOTE
1 Voltage range
• Units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above
listed range limits.
2 Maximum allowable voltage variation between phases is 2%.
3 Wire size & type must comply with the applicable local and national code.
• Wire size: Based on the value of MCA.
• Wire type: 60245 IEC57(IEC) or H05RN-F(CENELEC) grade or more.
4 MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
5 MCA represents maximum input current.
• MFA represents capacity which may accept MCA
• Abbreviations
MCA: Min. Circuit Amps. (A)
MFA: Max. Fuse Amps. (A)
