Installation Procedure
English
Installation Procedure
Main power cable specifications
The power cable is not supplied with air conditioner.
• Select the power supply cable in accordance with relevant local and national regulations.
• Wire size must comply with the applicable local and national code.
• Specifications for local wiring power cord and branch wiring are in compliance with local cord.
Model Outdoor unit Input current (A)
Power
supply
Indoor unit Outdoor unit
Hz
Voltage range (V)
Outdoor unit
Indoor
unit
Total
MCA
(A)
MFA
(A)
Rated Min
.
Max
.
Cooling Heating
AC018MN4DKH/VN
AC018MXADKH/VN
50/60 220-240 198 264 20 20 1.0 21.0 21.0 25.0
AC018MNMDKH/VN
50/60 220-240 198 264 20 20 2.5 22.5 22.5 25.0
AC024MN4DKH/VN
AC024MXADKH/VN
50/60 220-240 198 264 20 20 1.0 21.0 21.0 25.0
AC024MN4PKH/VN
50/60 220-240 198 264 20 20 1.5 21.5 21.5 25.0
AC024MNMDKH/VN
50/60 220-240 198 264 20 20 2.5 22.5 22.5 25.0
AC024MN4DKH/CB
AC024MXADKH/CB
60 220-240 198 264 20 20 1.0 21.0 21.0 25.0
AC024MN4PKH/CB
60 220-240 198 264 20 20 1.5 21.5 21.5 25.0
NOTE
1 Voltage range
• Units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above
listed range limits
2 Maximum allowable voltage variation between phases is 2%.
3 Wire size & type must comply with the applicable local and national code.
• Wire size: Based on the value of MCA.
• Wire type: 60245 IEC57(IEC) or H05RN-F(CENELEC) grade or more.
4 MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
5 MCA represents maximum input current.
• MFA represents capacity which may accept MCA
• Abbreviations
MCA: Min. Circuit Amps. (A)
MFA: Max. Fuse Amps. (A)
