11English
Cleaning and Maintenance
Cleaning the Air Conditioner
Cleaning and Maintenance
Cleaning the air filter
For the best performance from your air conditioner, clean it periodically. When cleaning, make
sure to unplug from the unit for user’s safety.
When cleaning the filter, make sure to unplug the power from the unit. Washable foam based
Air filter captures large particles from the air. The filter is cleaned with a vacuum or by hand
washing.
GLOBAL DUCT (Plastic Type)
1. Press both hooks and take the lter downward.
2. Clean the Air lter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running
water and dry it in a ventilated area.
• Forbestconditions,repeateverytwoweeks.
• IftheAirlterdriesinaconned(orhumid)area,odorsmaygenerate.Ifitoccurs,
re-clean and dry it in a ventilated area.
3. Insert the Air lter back in its original position.
