English

Installation Procedure

Key Push type Mode

Display

SEG 1 SEG 2SEG 3

SEG

4

K2 Short

1st Coolingtest

2nd Invertercheck

3rd Pumpdown

4th Stop

K3 Short 1st

Reset



ReleaseEcomode

• Forthecoolingonlymodels(AC012TXQLEC),

HeatingandDefrosttestmodes,activated

usingtheK1button,arenotavailable.

※

Defrosttestmode

Condition1:Theoutdoortemperatureisbelow10°C.

Condition2:Allthetemperatureconditionsshould

meetthedefrostconditions.

4 After12minutesoperationcheckdischargedair

temperatureofindoorunit

• Coolingmode(indoorunitcheck)→Inletair

temp.-Outletairtemp.:From10°Cto12°C

5 Howtoresetthepowersupplyoftheoutdoorunit

anddeactivatetheecomode(standbymode):

• PressK3buttonover1sectoresetthepower

supplyoftheoutdoorunitanddeactivatethe

ecomode(standbymode).

※

Ecomode:Standbyforminimizingpowerconsumption

6 Viewmode:WhentheK4switchispressed,youcansee

informationaboutoursystemstateasbelow

.

K4

short

push

Display contents SEG1 SEG2 SEG3 SEG4 Unit

1 Orderfrequency 1 Hundredsdigit Tensdigit

Unitsdigit

Hz

2 Currentfrequency 2 Hundredsdigit Tensdigit

Unitsdigit

Hz

3

Thenumberofpresetindoor

units

3 Hundredsdigit Tensdigit

Unitsdigit

EA

4 Ambienttemperaturesensor 4 +/- Tensdigit

Unitsdigit

°C

5 Compressordischargesensor 5 Hundredsdigit Tensdigit

Unitsdigit

°C

6 Eva-Midsensor 6 +/- Tensdigit

Unitsdigit

°C

7 Condensorsensor 7 +/- Tensdigit

Unitsdigit

°C

8 Current 8 Tensdigit Unitsdigit

Thefirstplaceof

decimals

A

9 OutdoorfanRPM 9 Thousandsdigit Hundredsdigit

Tensdigit

rpm

10 Targetdischargetemperature A Hundredsdigit Tensdigit

Unitsdigit

°C

11 EEV B Hundredsdigit Tensdigit

Unitsdigit

step

12

Thecapacitysumofindoor

units

C Tensdigit Unitdigit

Thefirstplaceof

decimals

kW

13 Protectivecontrol D

0:Cooling

1:Heating

Protectivecontrol

0:NoProtective

control

1:Freezing

2:Non-stopdefrosting

3:Over-load

4:Discharge

5:Totalelectriccurrent

Frequencystatus

0:Normal

1:Hold

2:Down

3:Up_limit

4:Down_limit

-

14 IPMtemperature E Hundredsdigit Tensdigit

Unitsdigit

-
