15

English

Installation Procedure

3 Insertbothsidesofcorewireofthepowercable

intotheconnectionsleeve.

• Method 1:Pushthecorewireintothesleeve

frombothsides.

• Method 2:Twistthewirecorestogetherand

pushitintothesleeve.

Connection sleeve

Method 1

Connection sleeve

Method 2

CAUTION

• Ifcablewiresareconnectedwithoutusing

connectingsleeves,theircontactareabecomes

reduced,orcorrosiondevelopsontheouter

surfacesofthewires(copperwires)overalong

time.Thismaycauseanincreaseofresistance

(reductionofpassingcurrent)andconsequently

mayresultinafire.

4 Usingacrimpingtool,compressthetwopoints

andflipitoverandcompressanothertwopointsin

thesamelocation.

• Thecompressiondimensionshouldbe8.0.

Compression

dimension

• Aftercompressingit,pullbothsidesofthewire

tomakesureitisfirmlypressed.

Compress it 4 times.

5 mm

Method 1

Compress it 4 times.

5 mm

Method 2

5 Applyheattothecontractiontubetocontractit.

Method 2

Method 1

Contraction tube Contraction tube

6 Wrapitwiththeinsulationtapetwiceormoreand

positionyourcontractiontubeinthemiddleofthe

insulationtape.

Method 2

Method 1

Insulation tape

40 mm

Insulation tape

35 mm

7 Aftertubecontractionworkiscompleted,wrapit

withtheinsulationtapetofinish.

Threeormorelayersofinsulationarerequired.

Method 2

Method 1

Insulation tape Insulation tape

CAUTION

• Makesurethattheconnectionpartsarenot

exposedtooutside.

• Besuretouseinsulationtapeandacontraction

tubemadeofapprovedreinforcedinsulating

materialsthathavethesamelevelofwithstand

voltagewiththepowercable.(Complywiththe

localregulationsonextensions.)

WARNING

• Incaseofextendingtheelectricwire,pleaseDO

NOTusearound-shapedPressingsocket.

– Incompletewireconnectionscancauseelectric

shockorafire.
