Installation Procedure

Outdoor-to-indoor power terminal specifications

• Connectthecablestotheterminalboardusingthecompressedringterminal.

• Coverasolderlessringterminalandaconnectorpartofthepowercableandthenconnectit.

Silver solder

Nominal

dimensions

for cable

(mm²)

Nominal

dimensions

for screw

(mm)

B D d1 E F L d2 t

Standard

dimension

(mm)

Allowance

(mm)

Standard

dimension

(mm)

Allowance

(mm)

Standard

dimension

(mm)

Allowance

(mm)

Min.

(mm)

Min.

(mm)

Max.

(mm)

Standard

dimension

(mm)

Allowance

(mm)

Min.

(mm)

4/6

4 9.5

±0.2 5.6

+0.3



-0.2

3.4 ±0.2 6.0

5 20.0 4.3

+0.2



0

0.9

8 15.0 9 28.5 8.4

+0.4



0

10 8 15.0 ±0.2 7.1

+0.3



-0.2

4.5 ±0.2 7.9 9 30.0 8.4

+0.4

0

1.15

16 8 16.0 ±0.2 9.0

+0.3



-0.2

5.8 ±0.2 9.5 13 33.0 8.4

+0.4

0

1.45

25

8 12.0

±0.3 11.5

+0.5



-0.2

7.7 ±0.2 11.0

15

34.0

8.4

+0.4

0

1.7

8 16.5 13 8.4

35

8 16.0

±0.3 13.3

+0.5



-0.2

9.4 ±0.2 12.5

13 38.0 8.4

+0.4

0

1.8

8 22.0 13 43.0 8.4

50 8 22.0 ±0.3 13.5

+0.5



-0.2

11.4 ±0.3 17. 5 14 50.0 8.4

+0.4

0

1.8

70 8 24.0 ±0.4 17. 5

+0.5



-0.4

13.3 ±0.4 18.5 20 51.0 8.4

+0.4

0

2.0

• Connecttheratedcablesonly.

• Connectusingadriverwhichisabletoapplytheratedtorquetothescrews.

• Iftheterminalisloose,firemayoccurcausedbyarc.Iftheterminalisconnectedtoofirmly,theterminalmay

bedamaged.

Tightening torque (kgfꞏcm)

M4 12.0to18.0

M5 20.0to30.0

• 1Nꞏm=10kgfꞏcm

CAUTION

• Whenconnectingcables,youcanconnectthecablestotheelectricalpartorconnectthemthroughthe

holesbelowdependingonthespot.

• Connectthecommunicationcablebetweentheindoorandoutdoorunitsthroughaconduittoprotect

againstexternalforces,andfeedtheconduitthroughthewalltogetherwithrefrigerantpiping.

• Removeallburrsattheedgeoftheknock-outholeandsecurethecabletotheoutdoorknock-outusing

liningandbushingwithanelectricalinsulationsuchasrubberandsoon.

• Mustkeepthecableinaprotectiontube.

• Keepdistancesof50mmormorebetweenpowercableandcommunicationcable.

• Whenthecablesareconnectedthroughthehole,removethePlatebottom.
