5 / EN

Washing Machine / User’s Manual

2 Installation

Refer to the nearest Authorised Service Agent for installation

of the product. To make the product ready for use, review

the information in the user manual and make sure that the

electricity, tap water supply and water drainage systems are

appropriatebeforecallingtheAuthorizedServiceAgent.If

theyarenot,callaqualifiedtechnicianandplumbertohave

any necessary arrangements carried out.

C

Preparationofthelocationandelectrical,tapwaterand

waste water installations at the place of installation is

undercustomer'sresponsibility.

Make sure that the water inlet and discharge hoses

aswellasthepowercablearenotfolded,pinchedor

crushed while pushing the product into its place after

installation or cleaning procedures.

B

warning: Installationandelectricalconnectionsof

theproductmustbecarriedoutbytheAuthorized

ServiceAgent.Manufacturershallnotbeheldliablefor

damagesthatmayarisefromprocedurescarriedoutby

unauthorized persons.

A

warning: Priortoinstallation,visuallycheckiftheproduct

hasanydefectsonit.Ifso,donothaveitinstalled.

Damagedproductscauserisksforyoursafety.

2.1 Appropriate installation location

• Placethemachineonarigidfloor.Donotplaceitona

long pile rug or similar surfaces.

• Totalweightofthewashingmachineandthedryer-with

full load- when they are placed on top of each other

reachestoapprox.180kilograms.Placetheproduct

on a solid and flat floor that has sufficient load carrying

capacity!

• Donotplacetheproductonthepowercable.

• Donotinstalltheproductatplaceswheretemperature

mayfallbelow0ºC.

• Placetheproductatleast1cmawayfromtheedgesof

other furniture.

2.2 Removing packaging reinforcement

Tiltthemachinebackwardstoremovethepackaging

reinforcement.Removethepackagingreinforcementby

pullingtheribbon.

2.3 Removing the transportation locks

A

warning: Donotremovethetransportationlocksbefore

taking out the packaging reinforcement.

warning: Removethetransportationsafetyboltsbefore

operatingthewashingmachine!Otherwise,theproduct

willbedamaged.

1.Loosenalltheboltswithasuitablespanneruntilthey

rotate freely

(C).

2.Removetransportationsafetyboltsbyturningthem

gently.

3.AttachtheplasticcoverssuppliedintheUserManualbag

into the holes on the rear panel.

(P)

C

Keepthetransportationsafetyboltsinasafeplaceto

reusewhenthewashingmachineneedstobemoved

again in the future.

Never move the product without the transportation safety

boltsproperlyfixedinplace!

2.4 Connecting water supply

C

Thewatersupplypressurerequiredtoruntheproductis

between1to10bars(0.1–1MPa).Itisnecessaryto

have10–80litersofwaterflowingfromthefullyopen

tap in one minute to have your machine run smoothly.

Attach a pressure reducing valve if water pressure is

higher.

Ifyouaregoingtousethedoublewater-inletproduct

as a single

(cold) water-inlet unit, you must install the

suppliedstoppertothehotwatervalvebeforeoperating

the product. (Applies for the products supplied with a

blindstoppergroup.)

A

warning: Modelswithasinglewaterinletshouldnotbe

connectedtothehotwatertap.Insuchacasethelaundry

will get damaged or the product will switch to protection

mode and will not operate.

warning: Donotuseoldorusedwaterinlethosesonthe

newproduct.Itmaycausestainsonyourlaundry.

1.Connectthespecialhosessuppliedwiththeproductto

thewaterinletsontheproduct.Redhose(left)(max.90

ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is

for cold water inlet.

A

warning: Ensure that the cold and hot water connections

are made correctly when installing the product.

Otherwise,yourlaundrywillcomeouthotattheendof

the washing process and wear out.

2.Tightenallhosenutsbyhand.Neveruseatoolwhen

tightening the nuts.

3.Openthetapscompletelyaftermakingthehose

connection to check for water leaks at the connection
