3 - EN

2 Installation

Removing packaging

reinforcement

Tiltthemachinetoremovethepackaging

reinforcement.Removethepackaging

reinforcementbypullingtheribbon.

Opening the transportation locks

A

Transportationsafetyboltsmustbe

removedbeforeoperatingthewashing

machine!Otherwise,themachinewillbe

damaged!

1. Loosenalltheboltswithaspanneruntil

theyrotatefreely(“C”)

2. Removetransportationsafetyboltsby

turningthemgently.

3. Fitthecovers(suppliedinthebagwiththe

OperationManual)intotheholesonthe

rearpanel.(“P”)

C

Keepthetransportationsafetyboltsin

asafeplacetoreusewhenthewashing

machineneedstobemovedagaininthe

future.

C

Nevermovetheappliancewithoutthe

transportationsafetyboltsproperlyfixedin

place!

Adjusting the feet

A

Donotuseanytoolstoloosenthelock

nuts.Otherwise,theycanbedamaged.

1. Manually(byhand)loosenthelocknutson

thefeet.

2. Adjustthemuntilthemachinestandslevel

andfirmly.

3. Important:Tightenalllocknutsupagain.

Connecting to the water supply.

Important:

• Thewatersupplypressurerequiredtorun

themachinemustbe1-10bar(0,1–1

MPa).

• Connectthespecialhosessuppliedwith

themachinetothewaterintakevalveson

themachine.

• Ifyouaregoingtouseyourdoublewater-

inletmachineasasingle(cold)water-inlet

unit,youmustinstallthestopper*,supplied

withyourmachinetothehotwatervalve.

• Ifyouwanttousebothwaterinletsofthe

product,youcanconnectthehotwater

hoseafterremovingthestopperand

gasketgroupfromthehotwatervalve.

*Appliesfortheproductssuppliedwithablind

stoppergroup.

• Modelswithasinglewaterinletshouldnot

beconnectedtothehotwatertap.

Whenreturningtheappliancetoitsplaceafter

maintenanceorcleaning,careshouldbetaken

nottofold,squeezeorblockthehoses.

Connecting to the drain

Thewaterdischargehosecanbeattachedto

theedgeofawashbasinorbathtub.Thedrain

hoseshouldbefirmlyfittedintothedrainasto

notgetoutofitshousing.

Important:

• Theendofthedrainhosemustbedirectly

connectedtothewastewaterdrainorto

thewashbasin.

• Thehoseshouldbeattachedtoaheightof

atleast40cm,and100cmatmost.

• Incasethehoseiselevatedafterlayingit

onthefloorlevelorclosetotheground

(lessthan40cmabovetheground),water

dischargebecomesmoredifficultandthe

laundrymaycomeoutwet.

• Thehoseshouldbepushedintothe

drainageformorethan15cm.Ifitistoo

longyoumayhaveitshortened.

• Themaximumlengthofthecombined

hosesmustnotbelongerthan3.2m.
