EN
7
If a live cable is damaged, switch off the appliance and disconnect the
cable from the mains supply.
• If you also use a robotic lawnmower for lawn care, the following safety
instructions must be observed with regard to the working area of the robotic
lawnmower:
– Always check the boundary wire area before scarifying on these areas.
– If the cables are laid in the ground, they must be checked, no cables
must be visible, and particular care must be taken with the charging
station.
– If the boundary wire is laid above ground, it should be stretched directly
over the ground and not lie slack in the grass. The cables must be
adequately secured with boundary pegs, see operating instructions.
– The limiting nails must not protrude, otherwise the nails must be
pressed down.
– Remove any cable residues lying around before scarifying.
In the conditions described above, there is a risk of the cable being pulled in
and wound up by the working tool, which can lead to serious injuries.
• Hanging branches and similar obstacles can injure the user or hinder
scarifying. Cables can get caught and be damaged or torn off. A damaged
cable can lead to a technical defect in the appliance. Before and during
scarifying, pay attention to possible obstacles such as hanging branches and
cut them back or remove them.
The electrical equipment must not be modified. Read and observe
the safety instructions for handling the battery and charger in the
respective separate operating instructions!
• Before using the scarifier, check that the screw connections are tight, that it
is correctly assembled and that the entire cutting unit is in good condition to
avoid any danger. Worn or damaged blades and fastening screws must be
replaced.
• The condition of the pictograms must be checked each time they are used.
Worn or damaged pictograms must be replaced.
Handling
• The batteries may only be charged with an authorised charger. You could
endanger yourself or damage your device.
Only use the scarifier with the batteries authorised for this purpose.
Incorrect use of batteries and charger can cause electric shock or fire.
Permitted chargers and batteries: see chapter "Original spare parts and
accessories".
• The appliance must not be operated in potentially explosive atmospheres.
Keep live cables away from the cutting tool.
Do not drive the machine over live cables when scarifying.
Check the area for live cables before and during scarifying and
remove them if possible.
Never drive over live cables with the cutting tool switched on. Danger:
electric shock!
If a live cable is damaged, switch off the appliance and disconnect
the cable from the mains supply.
• Do not scarify in bad weather when there is a risk of lightning strikes.
• Do not expose the appliance to rain or moisture.
• Do not wear headphones to listen to the radio or music. Safety during
maintenance and operation of the machine requires full attention.
• Scarify only in daylight or in good lighting conditions. Operate the machine
at walking pace.
• Be particularly careful when blind corners, bushes, trees or other obstacles
may impair visibility.
• Do not drive too close to holes, ditches and embankments. The machine can
suddenly roll over if a wheel drives over the edge of a ditch or an
embankment or if an edge suddenly gives way.
• Take care when scarifying under play equipment (e.g. swings). The
equipment could end up in an unsafe position. There is a risk of injury.
• Do not operate the machine if you are ill, tired or under the influence of
alcohol, medication or drugs.
• If possible, avoid using the appliance on wet grass. There is a risk of slipping.
• Always ensure a good, secure footing on slopes. Scarify across the slope,
never up or down. Be particularly careful when changing the direction of
travel on slopes.
• Do not scarify on excessively steep slopes! Scarifying on slopes
always harbours risks. Always ensure that you are standing securely.
Hand-held scarifiers should never be used on slopes steeper than 26%
(15° incline). There is a risk of losing stability!
• Be particularly careful when turning the machine or pulling the appliance
towards you.
• There is a risk of tripping when reversing with the machine. Avoid walking
backwards. Avoid abnormal body posture. Ensure that you are standing
securely and keep your balance at all times.
• Maintain the safety distance given by the length of the guide rail.
• To prevent the appliance from slipping when carrying it, always hold the
appliance by the gripping devices provided for this purpose (housing,
crossbar of the lower part of the guide rail).
• Note the weight of the machine before lifting or carrying (see chapter
"Technical data"). Lifting heavy weights can lead to health problems.
• Never lift or carry a machine with the motor running.
• Never use the machine with damaged or missing safety and protective
equipment.
Missing or damaged safety and protective equipment jeopardises your safety
and the safety of others.
Safety devices (see chapter "Description of components"):
– Safety switch bracket motor stop (1)
The scarifier is equipped with a motor stop device.
During operation and in the event of danger, the motor is
switched off by releasing the safety switch bracket.
The motor and the cutting tool must come to a standstill
(Caution! The cutting tool runs for a while!). Otherwise, visit the
nearest authorised specialist workshop.
After being released, the safety switch bracket must always
spring back into the position shown in the "Description of
components" illustration.
If this is not the case, an immediate inspection by an
authorised specialist workshop is required.
Ensure that the safety switch bracket is functioning properly. If
the safety switch bracket is not functioning properly, have it
repaired by an authorised specialist workshop.
– Battery(ies) (2)
This safety device protects against injuries caused by
unintentional starting of the engine.
To prevent unauthorised operation of the machine, all batteries
must be removed during all work on the machine, before
maintenance and repair work, when the machine is left and
during storage.
Protective devices (see chapter "Description of components"):
– Housing, splash guard (9)
These guards protect against injuries caused by objects being
thrown upwards.
The appliance must not be operated with a damaged housing
or without a properly attached splash guard.
– Housing
This protective device protects against injuries caused by
contact with the rotating cutting tool.
The appliance must not be operated with a damaged housing.
Ensure that hands and feet do not get under the housing.
– Belt drive covers (4)
These guards protect against injuries caused by moving parts.
The appliance must not be operated with damaged covers or
without properly fastened covers.
– Insulating elements (insulating connecting element (6)
insulating shells (8))
This protective device protects against injury from electric
shock.
The appliance must not be operated with damaged insulating
elements. Ensure that your hands are only in the designated
areas during use (upper part of the handlebar).
• The protective devices must not be modified.
During commissioning, ensure that the feet are at a safe distance
from the cutting tool.
When starting the engine, the machine must not be tilted upwards but,
if necessary, must be tilted by pressing down the guide rail so that the
cutting tool points in the direction away from the user, but only as far
as is absolutely necessary. As long as the appliance is not standing
with all 4 wheels on the ground, both hands must be on the upper part
of the handlebar.
Do not start the engine when people or animals are standing in front
of the mower.
Never place your hands or feet near or under rotating parts. Ensure
that hands and feet do not get under the housing.
Switch off the motor by releasing the safety switch bracket and make
sure that all moving parts are at a complete standstill and all batteries
are removed:
– if you leave the machine unattended;
– before checking, cleaning or working on the machine;
– if you need to lift or tilt the machine, e.g. for transport;
– when you transport the machine to and from the scarifying
area;
– when driving outside the lawn;
– before loosening blockages or clearing blockages in the
discharge duct;
– if a foreign body has been hit;
– when a fault occurs;
– if the machine starts to vibrate abnormally.
• If a foreign object has been hit and if the machine is blocked, e.g. by hitting
an obstacle, an authorised specialist workshop must check whether parts of
