GB
GB
Cautions
1. The induction hotplate must be installed by qualified
personnel or technicians.We have professionals at your service.
Please never conduct the operation by yourself.
2. The hob will not be installed directly above a dishwasher,
fridge, freezer,washing machine or clothes dryer, as the
humidity may damage the hob electronics.
3. The induction hotplate shall be installed such that better heat
radiation can be ensured to enhance its reliability.
4. The wall and induced heating zone above the table surface
shall withstand heat.
5. To avoid any damage, the sandwich layer and adhesive must
be resistant to heat.
6. A steam cleaner is not to be used.
INSTALLATION
How to attach the seal
Bottom of hob
Glass surface
Cloth
1. Put a towel or cloth on the work surface. Place the hob face
down on the protected surface.
2. Apply the strip seal, supplied with the hob, which is for sealing
it onto the work surface.
Do not use silicone. Apply the seal to the edge of the bottom of
the hob,leaving about 3mm from the edge of the glass. Apply
the seal all around the circumference.
Cut any excess and bring the two ends of the seal together so
they match.
Seal
Self-adhesive
seal
Under any circumstances,make sure the Induction cooker
hob is well ventilated and the air inlet and outlet are not
blocked.Ensure the Induction cooker hob is in good
workstate.As shown below
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
700 520 60 56 560 490 50 mini
55
54
