GB
65
Figure 2
NOTE
If the door is opened, ice or water cannot be taken from the door.
To ensure hygiene, it is recommended to pour out all the ice cubes made fully in the ice storage box for the
rst time.
If slamming the door, it may cause the water in the icemaker to splash into the ice storage box.
To prevent the ice storage box from accidentally falling, please operate with both hands when disassem-
bling the ice storage box.
To avoid personal injury, please clean up any water or ice that may fall on the ground. To avoid possible
injury to children, do not allow children to touch the ice fetching area or ice storage box.
Do not put your hands or any objects into the ice outlet channel, otherwise, it may cause personal injury or
damage to the parts of the ice storage box. To avoid possible injury, do not touch the ice outlet motor claw
with your hands, as shown in Figure 3.
The recommended external water pressure for the ice maker is (0.25~0.42) Mpa, and the nominal ice
making capacity is generally measured at 0.33Mpa. When the water pressure is not within the recommend-
ed range, the ice making function is normal, but the ice making volume will uctuate, which is a normal
phenomenon.
If it is impossible to get ice from the dispenser outside the door when the ice storage box is full of ice, it may
be because the ice impeller is stuck by ice. In such case, you need to manually remove the stuck ice, and
then the ice can be taken normally.
Figure 3
Ice outlet motor claw
Ice outlet channel
