6
■ Pruning saw jackets for upper body protection
– should comply with EN ISO 11393-6 and be CE
marked
ADDITIONAL BATTERY SAFETY WARNINGS
■ To reduce the risk of fire, personal injury, and product
damage due to short circuit, never immerse the tool,
battery pack, or charger in fluid or allow fluid to flow
inside them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach or
bleach-containing products, etc., can cause a short
circuit.
■ Charge the battery pack in a location where the ambient
temperature is between 10 °C and 38 °C.
■ Store the battery pack in a location where the ambient
temperature is between 0 °C and 20 °C.
INSTRUCTIONS CONCERNING THE PROPER
TECHNIQUES FOR BASIC LIMBING AND CROSS-
CUTTING
UNDERSTANDING THE FORCES WITHIN THE WOOD
When you understand the directional pressures and
stresses inside the wood, you can reduce the pinches or at
least expect them during your cutting. Tension in the wood
means the fi bres are being pulled apart, and if you cut in this
area, the kerf or cut tends to open as the saw goes through.
If a log is being supported on a saw-horse and the end is
hanging unsupported over the end, tension is created on
the upper surface due to the weight of the overhanging log
stretching the fi bres. Likewise, the underside of the log is
compressed and the fi bres are being pushed together. If a
cut is made in this area, the kerf tends to close up during the
cut. This cut would pinch the saw chain.
PUSH AND PULL
The reaction force is always opposite to the direction the
chain is moving. The operator must be ready to control the
tendency for the product to pull away and push backwards.
The product pulls away (forward motion) when cutting on
the bottom edge of the bar. The product pushes backwards
(towards the operator) when cutting along the top edge.
SAW JAMMED IN THE CUT
Turn off the product, and remove the battery pack. Do not
try to force the chain and bar out of the cut as this is likely
to break the chain, which may swing back and strike the
operator. This situation normally occurs because the wood
is incorrectly supported, which forces the cut to close under
compression, thereby pinching the saw chain. If adjusting
the support does not release the bar and chain, use wooden
wedges or a lever to open the cut and release the saw.
Never try to start the pruning saw when the guide bar is
already in a cut or kerf.
SKATING/BOUNCING
When the pruning saw fails to dig in during a cut, the guide
bar can begin hopping or dangerously skidding along the
surface of the log or branch, possibly resulting in the loss of
control of the pruning saw. To prevent or reduce skating or
bouncing, always use the saw with both hands. Make sure
that the saw chain establishes a groove for cutting.
Never cut small, fl exible branches or brushes with your
pruning saw. Their size and fl exibility can easily cause the
saw to bounce towards you or bind up with enough force
to cause a kickback. The best tool for that kind of work is
a hand saw, pruning shears, an axe, or other hand tools.
LIMBING A TREE
Limbing is removing the branches from a fallen tree. When
limbing, leave larger lower limbs to support the log off the
ground. Remove the small limbs in one cut. Branches under
tension should be cut from the bottom up to avoid binding
the pruning saw.
SPRINGPOLES
A springpole is any log, branch, rooted stump, or sapling
that is bent under tension by other wood so that it springs
back if the wood holding it is cut or removed.
On a fallen tree, a rooted stump has a high potential of
springing back to the upright position during the bucking
cut to separate the log from the stump. Watch out for
springpoles—they are dangerous. Do not attempt to cut
bent branches or stumps that are under tension unless you
are professionally trained and competent to do so.
WARNING! Springpoles are dangerous and could strike
the operator, causing the operator to lose control of the
pruning saw. This could result in a severe or fatal injury to
the operator. Cutting spring poles should be done by trained
users.
TRANSPORTATION AND STORAGE
■ Turn off the product, remove the battery pack, and allow
the product to cool down before storing or transporting.
■ Remove all foreign materials from the product. Store the
product in a cool, dry, and well-ventilated place that is
inaccessible to children. Keep the product away from
corrosive agents, such as garden chemicals and de-
icing salts. Do not store the product outdoors.
■ Fit the guide bar cover before storing the product or
during transportation.
