Royal Catering RCIC-1800P6 handleiding
Handleiding
Je bekijkt pagina 5 van 21
1. Button: ON/OFF
2. LED: the device is on
3. Button: value increase
4. Button: value reduction
5. Button: selection of the upper heating zone
6. Button: selection of the lower heating zone
EN
9
1. Hob
2. Control panel
DESCRIPTION OF CONTROL PANELS
Rev. 17.01.2022
i) Keep packaging elements and small assembly parts
in a place not available to children.
j) Keep the device away from children and animals.
k) If this device is used together with another
equipment, the remaining instructions for use shall
also be followed.
EN
8
2.3. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience
and/or knowledge unless they are supervised by
a person responsible for their safety or they have
received instruction on how to operate the device.
c) The device can be handled only by physically t
persons who are capable of handling it, properly
trained, familiar with this manual and trained within
the scope of occupational health and safety.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
2.4. SAFE DEVICE USE
a) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
o). Devices which cannot be switched on and o
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
b) Disconnect the device from the power supply
before commencement of adjustment, cleaning and
maintenance. Such a preventive measure reduces
the risk of accidental activation.
c) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
d) Keep the device in perfect technical condition.
Before each use check for general damage and
especially check for cracked parts or elements and
for any other conditions which may impact the safe
operation of the device. If damage is discovered,
hand over the device for repair before use.
e) Keep the device out of the reach of children.
f) Device repair or maintenance should be carried out
by qualied persons, only using original spare parts.
This will ensure safe use.
g) When transporting and handling the device between
the warehouse and the destination, observe the
occupational health and safety principles for manual
transport operations which apply in the country
where the device will be used.
h) Do not move, adjust or rotate the device in the
course of work.
i) Do not leave this appliance unattended while it is in
use.
j) Clean the device regularly to prevent stubborn grime
from accumulating.
k) The device is not a toy. Cleaning and maintenance
may not be carried out by children without
supervision by an adult person.
l) It is forbidden to interfere with the structure of
the device in order to change its parameters or
construction.
m) Keep the device away from sources of re and heat.
n) Keep aluminium foil and plastic dishes away from the
hob.
o) Do not store objects on the surface of the device.
p) Do not place metal cookware, cutlery, etc. near the
hob, as they may get hot and cause skin burns.
q) NOTE! rings, watches, chains etc. and other metal
objects may get hot in the vicinity of the device
which has been switched on.
r) Do not heat empty cookware on the hob.
s) The device should be used on a heat-resistant
surface.
t) NOTE! The hob remains hot for a long time after the
power is turned o. Touching a hot hob will cause
burns to the skin.
u) Do not use the cooker in the vicinity of devices
susceptible to electromagnetic radiation.
v) Only use cookware designed for use with induction
cookers.
w) Do not place the device on metal surfaces.
Rev. 17.01.2022
REMEMBER! When using the device, protect children
and other bystanders.
3. USE GUIDELINES
The device is designed for heating and cooking dishes
and liquids in cookware intended for use with induction
cookers. The product is intended for home use only!
The user is liable for any damage resulting from
unintended use of the device.
3.1. DEVICE DESCRIPTION
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
Error code Reason Solution
E0 There is no pan
on the cooker or
it is not suitable
Place a suitable
vessel on the cooker
E1 The device
becomes very
hot (e.g. covered
ventilation
openings)
Damaged parts
Clean the vents
(let the device cool
down, after this time
the device should be
ready for operation,
contact the service if
the error persists)
Contact the service
21
LOCK TIMER FUNCTION
POWER TEMP
ON/OFF
12
13
10
11
8 9
7
5
6
14
15
4 3
2
1
LIST OF DEVICES
a) DEVICES THAT CAN BE USED ON AN INDUCTION
COOKER
Steel or cast iron, enameled iron, stainless steel, at
bottomed pans/pots of 12-26 cm in diameter.
b) DEVICES THAT SHOULD NOT BE USED ON AN
INDUCTION COOKER
Heat-resistant glass, ceramic dishes, copper,
aluminum pans / pots, pans / pots with a rounded
bottom with a diameter of less than 12 cm.
3.4. CLEANING AND MAINTENANCE
a) Always unplug the device before cleaning it.
b) Use only non-corrosive cleaners to clean the surface.
c) After cleaning the device, all parts should be dried
completely before using it again.
d) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
e) Do not spray the device with a water jet or submerge
it in water.
f) Do not allow water to get inside the device through
vents in the housing of the device.
g) Clean the vents with a brush and compressed air.
h) The device must be regularly inspected to check its
technical eciency and spot any damage.
i) Use a soft, damp cloth for cleaning.
j) Do not use sharp and/or metal objects for cleaning
(e.g. a wire brush or a metal spatula) because they
may damage the surface material of the appliance.
k) Do not clean the device with an acidic substance,
agents of medical purposes, thinners, fuel, oils or
other chemical substances because it may damage
the device.
DISPOSING OF USED DEVICES
Do not dispose of this device in municipal waste systems.
Hand it over to an electric and electrical device recycling
and collection point. Check the symbol on the product,
instruction manual and packaging. The plastics used to
construct the device can be recycled in accordance with
their markings. By choosing to recycle you are making
a signicant contribution to the protection of our
environment. Contact local authorities for information on
your local recycling facility.
7. Button: function selection
8. LED: heating power setting mode
9. LED: heating temperature setting mode
10. Button: timer setting
11. LED: timer setting mode
12. Button: device lock
13. LED: device blocked
14. Display of parameters of the upper heating zone
15. Display of parameters of the lower heating zone
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device is
being used. There should be at least 10 cm distance between
each side of the device and the wall or other objects. Keep
the product away from hot surfaces. The device should
always be used when positioned on an even, stable, clean,
reproof and dry surface, and be out of the reach of children
and persons with limited mental and sensory functions.
Position the device such that you always have access to the
power plug. The power cord connected to the appliance
must be properly grounded and correspond to the technical
details on the product label.
3.3. DEVICE USE
HOW TO USE
1) Place a lled pot etc. centrally on the selected hotplate.
2) Connect the device to the power supply, then turn it
on by pressing the ON/OFF button. The LED above
the button will light up. The display will show „----“.
3) Select the upper ( ) or lower ( ) heating zone by
pressing the appropriate button.
4) In order to set the heating power or temperature of
a given zone, press the FUNCTION button and check
which function the diode (POWER- power, TEMP-
temperature) lights up on. Pressing the FUNCTION
button again will change the selected function.
Change the power and temperature by pressing the
+ or - buttons.
5) To set the TIMER option, select the zone again and press
the TIMER button. You can set the timer by pressing the
+ or - buttons between 0 and 180 minutes.
After selecting a function, press the lock button to lock the
selected settings. The LED above the lock indicator will turn
on. In order to make further changes or turn the device o,
hold the lock button until a double beep sounds.
TABLE OF ERRORS
E2 The device
turns o due to
overheating
Pull the plug out of
the socket, remove
the vessel from the
cooker, restart the
device after it has
cooled down
E3 Short-term
power failure
Remove the plug
from the socket,
reconnect after a few
minutes
