EN
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device
is being used. There should be at least 10 cm distance
between each side of the device and the wall or other
objects. Keep the product away from hot surfaces. The
device should always be used when positioned on an
even, stable, clean, reproof and dry surface, and be out
of the reach of children and persons with limited mental
and sensory functions. Position the device such that you
always have access to the power plug. The power cord
connected to the appliance must be properly grounded
and correspond to the technical details on the product
label.
Disassemble the device and all its components and clean
them before the rst use.
PLEASE NOTE:
1. DO NOT block the vents in the housing or in other
parts of the device
2. DO NOT use mechanical devices or other means to
speed up the defrosting process.
3. The refrigerant circuit must not be damaged.
4. Do not block the air inlet/outlet. The device draws
in cold air circulating within the refrigerator. The
blockage will close the air circulation.
5. Do not use electrical devices inside food storage
compartments
6. DO NOT to store explosive substances, such as aerosol
cans, and ammable materials inside the device.
ASSEMBLING THE DEVICE
1. Position the device in a dry place, so that at the sides
and at the back of the device there is a minimum
distance of 10cm to adjacent objects or walls.
Smaller distance may reduce the cooling capacity of
the device.
2. Before the rst start-up, wait at least 2 hours after
transporting the device in order to equalize the
refrigerant level in the device. Then, connect the
device to the power supply and turn it on.
3. Do not place the device in direct sunlight.
4. Do not place the device near heaters, it may reduce
its cooling capacity.
3.3. DEVICE USE
3.3.1. USE
1. Connect the device to the power supply.
2. After starting the device, place your hand on the
ventilation slots inside the cooling chamber and
verify that the air is cold enough.
3. Set the cooling temperature using the digital
temperature controller.
3.3.2. THE DIGITAL TEMPERATURE REGULATOR OPERATION
1. Setting the temperature
• Press the SET button to display the set temperature.
• Using the up and down buttons (arrows) you can
adjust the temperature range.
• Press the SET button to exit the temperature setting
on the control panel, the display will show the
temperature value inside the device.
2. If no buttons are pressed within 10 seconds, the
temperature inside the device will be displayed
automatically
3. To turn on the backlight, press the „bulb“ button.
When this button is pressed again, the backlight will
be turned o.
4. Manual defrost ON/OFF using the „light bulb“
button.
• To activate the defrost function, press and hold the
button for 6 seconds.
• To deactivate the defrost function, press the button
again.
5. Coolant LED
• While the device is running (cooling), the LED is on
• When low temperature inside the refrigerator
compartment is constant, the LED is on
• The LED will ash while the device start is delayed
• The LED during defrosting (defrosting) is on
• When defrosting is complete, the LED turns o
• The LED will ash if the defrosting is delayed
3.3.3. WARNINGS
1. Do not spray ammable substances in the vicinity of
the device. It is a re hazard.
2. After a power cut or the device disconnection from
the power supply, always wait at least 5 minutes,
then plug the device in and restart it.
3. The device is not designed to store medical supplies
or drugs.
4. It is not recommended to keep the device door open
for a long time or open it too often. It aects the
quality of keeping the cold air inside the device.
5. Do not put hot food into the device. Food must rst
be cooled to room temperature.
6. Never touch the compressor, it can cause severe
burns..
3.4. CLEANING AND MAINTENANCE
a) Always unplug the device before cleaning it.
b) Use only non-corrosive cleaners to clean the surface.
c) Use only mild, food-safe detergents to wash the
device.
d) After cleaning the device, all parts should be dried
completely before using it again.
e) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
f) Do not spray the device with a water jet or submerge
it in water.
g) Do not allow water to get inside the device through
vents in the housing of the device.
h) Clean the vents with a brush and compressed air.
i) The device must be regularly inspected to check its
technical eciency and spot any damage.
j) Use a soft, damp cloth for cleaning.
k) Do not use sharp and/or metal objects for cleaning
(e.g. a wire brush or a metal spatula) because they
may damage the surface material of the appliance.
l) Do not clean the device with an acidic substance,
agents of medical purposes, thinners, fuel, oils or
other chemical substances because it may damage
the device.
m) Before cleaning the refrigerator compartment, rst
remove everything stored inside and disconnect the
device from the power supply. Clean the inside with
a wet cloth, and then wipe everything dry.
EN
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there
is still a slight risk of accident or injury when using
the device. Stay alert and use common sense when
using the device.
3. USE GUIDELINES
The product is used to store food produce requiring
suciently low temperature.
The user is liable for any damage resulting from
unintended use of the device.
3.1. DEVICE DESCRIPTION
RCCC
-
78
-
W, RCCC
-
78
-
B
1. Glass pane
2. Air inlet
3. Rack with shelves
4. Air outlet
DISPOSING OF USED DEVICES
Do not dispose of this device in municipal waste systems.
Hand it over to an electric and electrical device recycling
and collection point. Check the symbol on the product,
instruction manual and packaging. The plastics used to
construct the device can be recycled in accordance with
their markings. By choosing to recycle you are making
a signicant contribution to the protection of our
environment. Contact local authorities for information on
your local recycling facility.
TROUBLESHOOTING
PROBLEM SOLUTION
No cooling
- Check that the device is properly
connected to the power supply
- Check that the fuse is not damaged
- Check if there is electricity in the
socket
Unsatisfactory
cooling level
- Check if the device has not been
placed in direct sunlight
- Check that there are no other devices
that emit heat in the vicinity of the
device
- Check that the device vents are not
blocked
- Check that the device door is closed
- Check that the seals are not
deformed or damaged
- Check that there is not too much
produce in the cooling compartment.
If so, reduce the amount of produce.
- Check that the food inside the
refrigerator is not blocking the vents
and restricting the circulation of cold
air
- Adjust the temperature controller
Noise
- Check that the device is well levelled
- Check that the device is not touching
the wall or another object
- Check that there are no loose objects
inside the device
Please note: The following phenomena should not cause
worry:
1. A sound of owing water can be heard while the
device is operating. This is normal as the coolant
circulates through the refrigeration system.
2. Condensation may form on the outside of the device
in wet seasons. Wipe the wet areas with a dry cloth.
10
11
RCCC
-
58
-
W, RCCC
-
58
-
B
Rev. 07.06.2022 Rev. 07.06.2022
