Rev. 23.03.2022 Rev. 23.03.2022
12 13
EN
3. To turn on the backlight, press the „bulb“ button [9].
When this button is pressed again, the backlight will
be turned o.
4. Defrosting function:
• o activate the defrost function, press and hold the
button [9] for 6 seconds.
• To deactivate the defrost function, press the button
[9] again.
5. Cooling LED [11]:
• While the device is running (cooling), the LED is on
• When low temperature inside the refrigerator
compartment is constant, the LED is on
• The LED [12] will ash while the device start is
delayed
6. Defrosting LED [12]:
• The LED during defrosting (defrosting) is on
• When defrosting is complete, the LED turns o
• The LED will ash if the defrosting is delayed
• Both LEDs will ash during a Delayed Start, i.e. the
time the machine must wait to restart operation.
7. Defrosting LED [12]:
• Hold the settings button [6] for 6 seconds. The
device will enter the setting adjustment mode.
• The device will display the possible parameters to be
changed: to change a displayed parameter, press the
button [6] when it is displayed and after changing
the value, conrm it with the same button [6]; to go
to the next parameter, press the buttons (arrows) [7]
and [8].
• After 10 seconds of inactivity, the device will exit the
settings menu and return to the normal operating
mode
8. Restoring factory settings:
• Press button [8] for 2 seconds. The device beeps.
• Then hold the [7] button for 6 seconds. The display
will start ashing.
• Wait 10 seconds. The device will return to the
operating mode in the factory settings.
9. Parameter change lock:
• Hold button [8] for 10 seconds. The message „OFF“
will start ashing on the display, which means that
changing the parameters according to which the
device operates is not possible.
• To unlock this function, press the [8] button again for
10 seconds until the display ashes „ON“.
3.3.3. WARNINGS
1. Do not spray ammable substances in the vicinity of
the device. It is a re hazard.
2. After a power cut or the device disconnection from
the power supply, always wait at least 5 minutes,
then plug the device in and restart it.
3. The device is not designed to store medical supplies
or drugs.
4. It is not recommended to keep the device door open
for a long time or open it too often. It aects the
quality of keeping the cold air inside the device.
5. Do not put hot food into the device. Food must rst
be cooled to room temperature.
6. Never touch the compressor, it can cause severe
burns.
3.4. CLEANING AND MAINTENANCE
a) Always unplug the device before cleaning it.
b) Use only non-corrosive cleaners to clean the surface.
c) Use only mild, food-safe detergents to wash the
device.
d) After cleaning the device, all parts should be dried
completely before using it again.
e) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
f) Do not spray the device with a water jet or submerge
it in water.
PROBLEM SOLUTION
No cooling
- Check that the device is properly
connected to the power supply
- Check that the fuse is not damaged
- Check if there is electricity in the
socket
Unsatisfactory
cooling level
- Check if the device has not been
placed in direct sunlight
- Check that there are no other devices
that emit heat in the vicinity of the
device
- Check that the device vents are not
blocked
- Check that the device door is closed
- Check that the seals are not
deformed or damaged
- Check that there is not too much
produce in the cooling compartment.
If so, reduce the amount of produce.
- Check that the food inside the
refrigerator is not blocking the vents
and restricting the circulation of cold
air
- Adjust the temperature controller
Noise
- Check that the device is well levelled
- Check that the device is not touching
the wall or another object
- Check that there are no loose objects
inside the device
g) Do not allow water to get inside the device through
vents in the housing of the device.
h) Clean the vents with a brush and compressed air.
i) The device must be regularly inspected to check its
technical eciency and spot any damage.
j) Use a soft, damp cloth for cleaning.
k) Do not use sharp and/or metal objects for cleaning
(e.g. a wire brush or a metal spatula) because they
may damage the surface material of the appliance.
l) Do not clean the device with an acidic substance,
agents of medical purposes, thinners, fuel, oils or
other chemical substances because it may damage
the device.
m) Before cleaning the refrigerator compartment, rst
remove everything stored inside and disconnect the
device from the power supply. Clean the inside with
a wet cloth, and then wipe everything dry.
DISPOSING OF USED DEVICES
Do not dispose of this device in municipal waste systems.
Hand it over to an electric and electrical device recycling
and collection point. Check the symbol on the product,
instruction manual and packaging. The plastics used
to construct the device can be recycled in accordance
with their markings. By choosing to recycle you are
making a signicant contribution to the protection of our
environment. Contact local authorities for information on
your local recycling facility.
TROUBLESHOOTING
EN
Dis-
played
code
Function Setting range Factory
setting
E1 Lower
temperature
limit
-20
o
C / -4oF 2
o
C / 36
o
F
E2 Upper
temperature
limit
49
o
C / 120
o
F 6
o
C / 43
o
F
E3 Temperature
uctuation
1 – 10
o
C / 2 –
18
o
F
4oC / 7
o
F
E4 Delayed start 0 – 10 (minutes) 5
E5 Room
temperature
sensor
-5 – 5
o
C / -9
– 9
o
F
-2
o
C / 4
o
F
E6 Cooling
temperature
sensor
0
o
C / 0
o
F
F1 Cooling time 1 – 60 (minutes) 25
F2 Cooling cycle 0 – 24 (hours) 4
F3 Cooling end
temperature
0 – 20
o
C / 32
– 68
o
F
20
o
C /
68
o
F
F4 Displayed
temperature
0 - room tem-
perature
1 - cooling
temperature
(at setting „1”:
the room tem-
perature will be
displayed after
a defrosting
process is com-
pleted and after
a 20-minute
delayed start)
0
C1 Temperature
unit
0 –
o
C
1 –
o
F
0
Please note: The following phenomena should not cause
worry:
1. A sound of owing water can be heard while the
device is operating. This is normal as the coolant
circulates through the refrigeration system.
2. Condensation may form on the outside of the device
in wet seasons. Wipe the wet areas with a dry cloth.
