Please read carefully the “Safety and use instructions” booklet before first use.

BEFORE USE

DESCRIPTION

1. Smart Led Screen with

electronic temperature control

2. Mode button

3. Steam trigger

4. Cord

5. Handle

6. Water tank

7. High precision tip

8. Soleplate

9. Filling inlet

10. Rear cover

Innovative Steam Power Control technology provides stunning results with ﬂawless precision.

Let's break the rules of performance. The powerful pump system inspired by Rowenta's line

of steam stations provides up to 2X more steam into the fabric* to achieve perfect results.

The Steam Power Control Technology allows perfect control over the steam power. A smart

trigger enables you to control the amount of steam and activate it only when you need, for

a personal experience.

Smart control panel has 5 pre-settings for different fabric types. Smart controls will

automatically adapt to a precise temperature of the soleplate and steam output. There's no

need to worry about burning your fabrics.

* compared to an iron with no pump, Rowenta DW53xx

STEAMFORCE PRO, CONCENTRATED INNOVATION…

1 • Filling the water tank

• Before filling the water tank, unplug the iron ﬁg 1.

• Open the water filling inlet ﬁg 2. Fill in water up to the Max. mark. ﬁg 3. Close the

filling inlet and return the iron to the horizontal position.

• You can plug in your iron ﬁg 4

2 • Setting the temperature

Your iron is equipped with the Autosteam Electronic Control function, it automatically

adjusts the steam amount and the temperature based on the selected fabric for

optimum results. Select the fabric to be ironed by pressing the MODE button to

select the appropriate fabric. ﬁg 5. For perfect results, an optimum position for each

fabric has been pre-defined.

When your iron reaches the required temperature, the selected fabric in the LED

screen stops flashing and is displayed constantly ﬁg 6. You can start ironing.

USE

SCREEN

INDICATION

FABRIC IRONING LABEL

NYLON

nylon (Synthetic

fibres, e.g. viscose,

polyester)

SILK silk

WOOL wool

COTTON cotton

LINEN linen

IMPORTANT The iron takes longer to cool down than to heat up. We recommend

that you start with fabrics to be ironed at a low temperature. For mixed fabrics set the

temperature for the most delicate fabric.

TIP: Always spray starch onto the reverse side of the fabric to be ironed.

4 • Steam ironing

This iron is equipped with an on-demand steam trigger so you can activate the steam only

when needed and control the steam output according to your needs.

To start the steam output, press continuously the trigger to the first level

ﬁg 7-a or below.

On linen and cotton mode only, to eradicate the toughest creases, you can activate the steam

boost: press the trigger to the max level (1 seconde max) and release (

ﬁg 7-b or below). Wait

a few seconds between each shot before pressing the trigger again.

3 • Dry ironing

For dry ironing, do not press the steam trigger. Ideal for delicates or perfect finishing.

CONTINUOUS STEAM

STEAM BOOST

CONTINUOUS STEAM

STEAM BOOST

IMPORTANT Leave an interval of a few seconds between each shot and wait until the

flow of steam has finished before standing the iron on its heel.

5 • Vertical shot of steam

Select the Linen mode and hold the iron vertically. Press the trigger to the max level to activate

the shot of steam to remove creases from suits, jackets, skirts, hanging curtains etc.

ﬁg 8. Wait

a few seconds between each shot before pressing the trigger again.

TIP Hold the iron 20 centimetres away from the garment to avoid burning delicate

fabrics.

IMPORTANT Never direct the steam at persons or animals!

On NYLON mode, the steam is blocked in order to protect your clothes.
