Rowenta Silence Force Extreme Cyclonic RO8221 handleiding

Niet gecategoriseerd

Rowenta

73 pagina's

PDF beschikbaar

Handleiding

* According to model: these systems are specific to certain mo-

dels or are accessories available as an option.

The air we breathe contains particles that can be allergenic: larva

and dust mite faeces, mould, pollen, smoke and animal waste

(

hair, skin, saliva, urine), etc.

The finest particles can penetrate deep inside the respiratory

ystem or can cause inflammation and affect the entire

respiratory system.

(

H)EPA ([High] Efficiency Particulate Air Filter) filters retain the

finest particles.

Thanks to the (H)EPA filter, the air released into the room is

cleaner than the air suctioned.

1 • Emptying the dust compartment (5)

After each use, empty the dust compartment as follows:

Take the dust compartment by the handle and remove it (fig.15).

Separate the fine dust compartment (5b) from the main

compartment (5a) (Fig.16).

Empty the main compartment over a dustbin (Fig.17) then

empty the fine dust compartment (5b) (Fig.18).

Clean the compartment seals using a cloth.

Reposition the fine dust compartment on the main

compartment (Fig.19) then put the dust compartment back into

place (fig.20).

2 • Cleaning the black foam filter

(18a)

Press the cover release button (fig.21). Tip the cover

backwards (fig.22).

Remove the black foam filter (fig.23) then wash and squeeze

it (fig.24). Leave to dry for at least 12 hours before refitting.

Reposition the black foam filter and close the cover.

3 • Cleaning the microfilter (18b)

Press the cover release button (fig.21). Tip the cover

backwards (fig.22).

Remove the filtration cassette (18) then separate the black

foam filter (18a) from the microfilter (18b) (fig.25).

ash the microfilter (fig.26). Leave to dry for at least 12

hours before refitting.

Reposition the black foam filter and close the cover.

4 • Cleaning the HEPA filter (17)

Remove the accessory support* then place the vacuum

cleaner in the vertical position (Fig.27).

Open the HEPA filter hatch (Fig.28).

Remove the HEPA filter from its housing (fig.29). Clean the

HEPA filter by gently patting it over a dustbin (fig. 30).

Reposition it in its housing (Fig.31).

Reposition the hatch until you hear a click indicating that it is

closed (Fig. 32).

5. Cleaning the air/dust separator

system (4)

Remove the hose from the vacuum cleaner.

Open the vacuum cleaner cover (fig. 21-22).

Press the separator release button (fig.33) then remove from

the separation system (fig.34).

Remove the separation compartment (4c) by turning slightly

to the left (fig.35) then separate the two components (fig.36).

Wash the components (4a+b and 4c) in clear water (fig. 37)

and leave to dry for 6 hours.

Refit the filter system components (4):

- Reposition the separation compartment (4c) on the

separation system (4a+b) (fig. 38) by turning slightly until you

hear the click indicating that it is closed (fig. 39).

- Then reposition the entire separation system (4) in the

appliance (fig. 40) and close the cover.

CLEANING AND MAINTENANCE

IMPORTANT: always switch off and unplug your vacuum

cleaner before cleaning or servicing. Check and clean your

vacuum cleaner and the different filters regularly.

IMPORTANT: do not use the vacuum cleaner once the

maximum level (6) is reached on the dust compartment.

IMPORTANT: do not operate your vacuum cleaner

without the filtration system fitted (foam,

microfilter and filter).

IMPORTANT: clean the black foam filter every 6 months or

when the suction is no longer satisfactory.

ATTENTION: let the black foam filter dry completely

and make sure it is completely dry before placing it

back in the appliance.

IMPORTANT: clean the microfilter every 6 months.

TTENTION: let the microfilter dry completely and

make sure that it is well dry before refitting on the

ppliance.

IMPORTANT: if the appliance does not perform as normal

after cleaning the black foam filter and microfilter on your

vacuum cleaner, clean the HEPA filter.

ATTENTION: your appliance is equipped with a

safety system (19) for detecting the filtration

cassette: the cover cannot be closed if the filtration

cassette is not fitted (18a+18b).

IMPORTANT: replace the HEPA filter every 12 months.

The HEPA filter (ref ZR9015.01) is available from your

dealer or in Approved Service Centres.
