ENGLISH
9
Bending capacity:.............................................. 12 – 35 mm
Bending angle:.................................................. 0º - 180º
Voltage: ............................................................ 230 V 50/60 Hz
100 V 50/60 Hz
110 V 50/60 Hz
Absorbed power: .............................................. 1010 W (900W)
On-switch: ........................................................ Non-blocking
Machine weight: ............................................... 13 kg.
Machine dimensions: ........................................ 590 x 145 x 215
Complete set weight (12,15,18 and 22 mm): .... 24 kg.
Box dimensions: ............................................... 660 x 430 x 200 mm
Noise level: ....................................................... 100 dBA
Lp: .................................................................... 87 db
Vibration level: .................................................. 5,9 m/s
2
1. Motor
2. Reverse lever
3. Handle
4. Bolt housing
5. Tripod
6. Former
7. Former hook
8. Former fastening shaft
9. Slide
10. Slide fastening bolt
11. Series bending scale
Hard and soft Cu-Al DIN 1786 Øs 12 a 35 mm: 1,2 mm pared.
Hard and soft steel DIN 2391, DIN 2393, DIN 2394; Øs 12 a 28 mm x 2,5.
Steel DIN 2440 1/4” (14), 3/8” (18), 1/2 “ (22), 3/4 “ (28).
INOX AISI 304-316 espesor hasta 1,5 mm Øs 12 a 28 mm
Conduit: 16-20-25-32-35 mm
1. Safety in the work area
• Keep the work area clean and tidy. Untidy or dirty areas are more likely to cause accidents.
• Keep children and spectators away when using the power tool. Distractions can make you lose control of
the saw.
2. Electrical safety
• The plugs of power tools must fit in the sockets. Do not modify the plugs under any circumstances. Do not
use adaptor plugs with earthed power tools. If you use unmodified plugs and the corresponding sockets, you
will reduce the risk of electric shocks.
• Avoid touching earthed surfaces, such as piping, radiators, chains or coolers. The risk of electric shocks
increases if the body is connected to earth.
• Do not expose power tools to rain or moist conditions. If water penetrates a power tool, this increases the
risk of electric shocks.
• Take proper care of the cable. Do not use the cable to move, drag or unplug the power tool. Keep the
3. Capacity
4. General safety instructions
2. Machine components (See figure A)
1. Technical characteristics
UA-10
