ENGLISH
11
6. Starting up
7. Care and maintenace
6. Device for series bending (See figure B.4)
The unit provides a device for setting the bending angle automatically from 0º to 180º. To operate,
loosen the graduated scale surrounding the former shaft and align the desired angle with the inner
mark as shown. See Figure. Once the angle has been selected, tighten and proceed according to the
“start-up” chapter. IMPORTANT: Do not use this option for pipes ≥ Ø 28 mm x 1.2 mm
7. Keepaway from moving parts
Make sure that your hands are not in contact with moving parts of the machine during the bending
process.
Before carrying out any operation with this unit, first read the general safety instructions and
preparation for start-up.
Important: For all bending applications, carefully follow the steps described beolw
1. Select the tube or pipe to be bent. Choose the relevant bending former and shoe suited to the
tubes size. Ensure that the ROBEND
®
4000 is set in the start position by starting the motor with the
direction lever in the reserve position until it triggers off and moves to the neutral position.
2. Place the bending former onto the centrepin. Lay the tube into the bending former and secure it into
the hook.
Important: Ensure that the tubes is fully inserted into the hook and has contact with the whole hook
surface. Secure the bending shoe with the fastening bolt into the appropriate housing.
3. Ensure you are at the correct starting position by checking the “0” mark on the bending former is lined
up with the centre of the bending shoe (see figure C.A).
4. To start bending, shift the direction lever to the working position and push the power switch
. The
bending former will start to rotate. Maintain pressure on the switch until your chosen angle of bend
(marked on the bending former) (see figure C.B) lines up with the mark on the bending shoe, and then
release the switch (see figure C.C).
5. The ROBEND
®
4000 is equipped with a device that allows you to preset the bending angle between 0
to 180 degrees which is ideal for repeat bends. See “preparation for start up” chapter.
6. Once the been has bend produced and the power switch has been released, shift the direction lever
back into the reverse position
. Now, briefly push the power switch to loosen the hold on the tube.
Once the tube has released you can remove the fastening bolt, then the bending shoe and finally
take the finished bend out of the bending former.
7. In order to make the ROBEND
®
4000 ready for the next bending operation, start the motor with the
direction lever in the reverse position
until it triggers off and moves into the neutral position.
Before carrying out any job on the machine, disconnect the plug from the mains outlet.
1. Cable and plug
Both the cable and plug should be in optimum condition. Check them at regular intervals.
2. ON switch
Check that the machine switch unblocks automatically when finger pressure is released. In case of
any anomaly, replace immediately with a new one.
3. Brushes
Check frequently for brush wear and perfect contact with rotor. Change brushes when their lengths
is 1/3 of original length. Use original ROTHENBERGER brushes.
