56
ENGLISH
Structure and Possible Combinations
Additional Equipment
Connecting the mains adapter
or USB-C cable
– Connect the mains adapter to the DC
connection [13].
Take care not to leave the mains
adapter hanging in the air. Use the wire
ring to attach the mains adapter to the
lamp tripod.
– Connect a USB-C cable to the USB-C
port [12] on the COB permanent light.
Note: Only use a USB power adapter
with at least 65 W output power.
Connecting the battery handle 71 Wh
– The LUX battery handle 71 Wh is only compatible with the LUX 60
W and LUX 100 W lamp series.
– Make sure that the LUX battery handle is switched off before
installing it. Only switch it on after it has been attached to the
lamp.
– Align the battery connector and 1/4‘ screw on the top of the LUX
battery handle with the battery connector and 1/4’ connector [7]
on the lamp. Then turn the locking wheel [18] to lock it in place.
Make sure the locking wheel [18] is securely in place before
turning on the battery handle.
– To remove the battery grip, turn the locking wheel [18] in the
opposite direction.
Align
Unlock
Lock
1
2
3
2
1
3
