84
SPECIFICATIONS
Specifications
Camera type
Single-lens autofocus reflex camera with auto-
matic multi-exposure control, variable metering
pattern, TTL autoflash (SCA-3002) and motor-
ized film advance when using magazine 4560.
Autofocus
Cross-type autofocus sensor. Integral red-light
grid projector for autofocusing in poor light.
Non-AF Rolleiflex 6008-compatible PQ/PQS
lenses can be used with focus indicator.
Film negative sizes
4,5 x 6 cm and 6 x 6 cm
(6 x 6 cm in preparation)
Film types
Size 120 and 220 roll film for 16 or 32
4.5 x 6cm exposures.
Film speed
ISO 25/15° to 6400/39° can be set on inter-
changeable magazine in 1/3 increments.
Shutter
Electronically controlled between-the-lens
shutter for speeds from 1/1000 s (with PQS
lenses) to 32 seconds plus B and T.
Exposure metering
» Multizone average metering.
» Centre-weighted multizone metering.
» Spot metering via central photodiode
(approx. 1% of 6 x 6 film frame).
» Automatic compensation of extraneous
light during metering.
» Integral RGB sensor for automatic white
balance in digital photography.
Exposure functions
» Shutter-priority AE.
» Aperture-priority AE.
» Programmed AE biased for fast shutter speeds.
» Metered manual in 1/3 increments.
Working ranges
» Exposure metering EV 0 to EV 19 at
ISO 100/21° with 80mm f/2.8 lens
» Automatic focusing EV 1 to EV 19 at
ISO 100/21° with 80mm f/2.8 lens
» TTL flash ISO 25 – 1600
AE/AF lock
Enabled in all automatic-exposure modes.
Locks in EV of shutter speed and aperture.
Exposure compensation
» Manual setting range from -5 to +5 EV,
in 1/3 increments.
» In bracketing mode in increments of 1/3,
2/3 and 1 EV.
Autoflash
OTF TTL metering.
Automatic flash firing possible with dedicated
Metz flash units in case of poor light.
Additive fill-in flash.
Flash synchronization
At all speeds from 1/1000 s to 32 s.
Hot shoe with contacts for dedicated Metz
flash units.
SCA interface via Rollei SCA-3562 adapter.
Minimum shutter lag
Ultra-fast shutter response with approx. 3 – 4 ms
delay between shutter triggering and exposure,
with PQ lenses. With PQS lenses, shutter lag is
only approx. 2 s. Additional automatic stand-by
mode after shutter release is possible.
