R-44 4-Channel Monitoring Chart
* Channel names (p. 18)
* Output Assignment (p. 18)
Format: MONOx4
Chan-
nel
names
Output
Assign-
ment
Output Jack
Output Select
(Type)
4-indiv Monitor
1L L 1/L Mic 1 Mic 1+3
1R R 2/R Mic 2 Mic 2+4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 1+3 Mic 1+3
Headphone R Mic 2+4 Mic 2+4
1L L 1/L Mic 1 Mic 1
1R R 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1 Mic 1
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 4 Mic 4
1L LR 1/L Mic 1 Mic 1+3
1R LR 2/R Mic 2 Mic 2+4
2L LR 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic
1+2+3+4
Mic
1+2+3+4
Headphone R Mic
1+2+3+4
Mic
1+2+3+4
1L LR 1/L Mic 1 Mic 1
1R 2/R Mic 2 Mic 1
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1 Mic 1
Headphone R Mic 1 Mic 1
1L 1/L Mic 1 Mic 1
1R LR 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 2 Mic 2
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 3
2L LR 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 3 Mic 3
1L 1/L Mic 1 Mic 4
1R 2/R Mic 2 Mic 4
2L 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic 4 Mic 4
Headphone R Mic 4 Mic 4
1L 1/L Mic 1 None
1R 2/R Mic 2 None
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L None None
Headphone R None None
Format: 4CHx1
Chan-
nel
names
Output
Assign-
ment
Output Jack
Output Select
(Type)
4-indiv Monitor
1L L 1/L Mic 1 Mic 1+3
1R R 2/R Mic 2 Mic 2+4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 1+3 Mic 1+3
Headphone R Mic 2+4 Mic 2+4
1L L 1/L Mic 1 Mic 1
1R R 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1 Mic 1
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 4 Mic 4
1L LR 1/L Mic 1 Mic
1+2+3+4
1R LR 2/R Mic 2 Mic
1+2+3+4
2L LR 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic
1+2+3+4
Mic
1+2+3+4
Headphone R Mic
1+2+3+4
Mic
1+2+3+4
1L LR 1/L Mic 1 Mic 1
1R 2/R Mic 2 Mic 1
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1 Mic 1
Headphone R Mic 1 Mic 1
1L 1/L Mic 1 Mic 2
1R LR 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 2 Mic 2
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 3
2L LR 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 3 Mic 3
1L 1/L Mic 1 Mic 4
1R 2/R Mic 2 Mic 4
2L 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic 4 Mic 4
Headphone R Mic 4 Mic 4
1L 1/L Mic 1 None
1R 2/R Mic 2 None
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L None None
Headphone R None None
Format: STEREO x 2
Chan-
nel
names
Output
Assign-
ment
Output Jack
Output Select
(Type)
4-indiv Monitor
1L L 1/L Mic 1 Mic 1+3
1R R 2/R Mic 2 Mic 2+4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 1+3 Mic 1+3
Headphone R Mic 2+4 Mic 2+4
1L L 1/L Mic 1 Mic 1
1R R 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1 Mic 1
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 4
2L L 3/L Mic 3 Mic 3
2R R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 4 Mic 4
1L LR 1/L Mic 1 Mic
1+2+3+4
1R LR 2/R Mic 2 Mic
1+2+3+4
2L LR 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic
1+2+3+4
Mic
1+2+3+4
Headphone R Mic
1+2+3+4
Mic
1+2+3+4
1L LR 1/L Mic 1 Mic 1
1R 2/R Mic 2 Mic 1
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 1+2 Mic 1
Headphone R Mic 1+2 Mic 1
1L 1/L Mic 1 Mic 2
1R LR 2/R Mic 2 Mic 2
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 2 Mic 2
Headphone R Mic 2 Mic 2
1L 1/L Mic 1 Mic 3
1R 2/R Mic 2 Mic 3
2L LR 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L Mic 3 Mic 3
Headphone R Mic 3 Mic 3
1L 1/L Mic 1 Mic 4
1R 2/R Mic 2 Mic 4
2L 3/L Mic 3 Mic 3
2R LR 4/R Mic 4 Mic 4
Headphone L Mic 4 Mic 4
Headphone R Mic 4 Mic 4
1L 1/L Mic 1 None
1R 2/R Mic 2 None
2L 3/L Mic 3 Mic 3
2R 4/R Mic 4 Mic 4
Headphone L None None
Headphone R None None
