3
Specications
CEA-2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle
power under continuous demand, not instantaneous power handling that over time can damage voice coils.
VERIFIED WITH KLIPPEL
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained and certified by
Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate has made the investment in Klippel to
deliver the best possible speakers and subwoofers to their customers.
Model TMS14-65
Nominal Diameter - inch
(mm)
6.5
(165)
Description 2-Way
Nominal Impedance (Ohms) 4Ω
Frequency Response (Hz)
50-20k
Voice Coil Diameter - inch
(mm)
1.5
(38.6)
Power Handling - Watts
(RMS/Peak)
150/300
Fs - Free Air Resonance (Hz) 72.5
Qts 0.43
Vas - cu. ft.
(Liter)
0.215
(6.1)
Sensitivity (1W/1M) 90.6dB
Sensitivity (2.83V/1M) 93.6dB
Xmax - inch
(mm)
0.17
(4.5)
Mounting Diameter
5.0
(128)
Mounting Depth
2.1
(53)
Grille/Trim Ring YES
IPX6 is the water ingress prevention rating of this product. Here’s a breakdown of everything needed for the IPX6 test: A 0.5” (12.5mm) nozzle
with 15 psi (100 kpa) outputting 100 liters/minute of water from a distance of 9.8’ (3 meters) from all directions for at least 3 minutes.
