10
IN THE EXTRACTION MODE:
a. Fit the non-return backow aps C over the round outlet item 6 on top of the canopy while pressing
down until they snap into position, and then connect the ducting 150mm (6 INS) and secure the connec-
tions with appropriate clamping rings or adhesive tape (F ig . 8).
b. Before tting the chimney to the canopy make the electrical connection as described in the section
titled ELECTRICAL.
c. Each top and lower chimney stack consists of two sections. Place the top chimney with the slops fac-
ing downwards (F ig . 6c - item 7a) when installing the ducting version and secure the chimney stacks to
the brackets using the M4 screws provided.
d . Check the vertical of the chimney.
e . Place the lower chimney 7b as illustrated in F ig 9 & 1 0 .
IN THE RECIRCULATION MODE:
a. Fit the recirculation spigot R onto the chimney bracket using the same xing screws F ig . 6a.
b. Connect the ducting 150mm (6 INS) not provided between motors item 6 and the recirculation spigot
and secure the connections with appropriate clamping rings or adhesive tape (F ig . 6c ).
c. Make the electrical connection as described in the section titled ELECTRICAL.
d. Each top and lower chimney stack consists of two sections. Place the top chimney with the slops fac-
ing upwards (F ig . 6c - item 7a) when installing the recirculation version and secure the chimney stacks
to the brackets using the M4 screws provided.
e . Check the vertical of the chimney.
f . Place the lower chimney 7b as illustrated in F ig 9 & 1 0 .
• FITTING THE CANOPY ONTO THE CHIMNEY
9) Check the connectors of the motor as illustrated in F ig . 1 1 .
10) Test the lights and the fan motor.
11) Remove the metal grease lters. Insert the charcoal lter into the base of the motor housing and
secure the lter with two securing straps A as illustrated F ig . 6d.
12) Fit the metal grease lters.
G B
