6

INSTALLATION

Any adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the

ambient temperature of the room it is located in, during periods of use. The power supply to the

appliance must be switched off before any adjustments or maintenance work is done on it.

Preparation for Installation and Use

Manufactured with best quality parts and materials, this modern, functional and practical oven with cooktop will

meet your needs in all respects. Make sure to read the manual to obtain successful results so as not to

experience any problems in the future. The information given below contains rules that are necessary for correct

positioning and service operations. They should be read without fail, especially by the technician who will

position the appliance.

Installation of Oven

The oven can be placed close to other furniture on the condition that the oven is at least 10mm higher than the

level of the surrounding furniture. Do not place the oven near a refrigerator.

When choosing a place for the oven, ensure that there are no flammable or combustible materials in close

vicinity, such as curtains, oil, cloth etc. These can quickly catch fire.

There must be at least a 2 centimetre clear space between the back cover of oven and any wall for air circulation.

Furniture surrounding the oven must be made of materials resistant to temperatures 85°C above ambient

temperature or more.

The oven is designed to fit between kitchen cabinets spaced over 550mm apart. The space either side of the oven

needs only be sufficient to allow withdrawal of the oven for servicing. It can be used with cabinets on one side or

both sides as well as in a corner setting. It can also be used free-standing.

Installation Steps

 Determine the position for the oven and anti-tilt plate.

 Securely fix the anti-tilt plate to the floor with the appropriate fasteners.

 Fasten the stability bolt bracket to the front frame with the two screws supplied.

 Position the oven into the anti-tilt plate and mark the position of the stability bolt hole.

 Remove the oven and drill the bolt hole at the marked location. Use a 10mm masonry or wood drill bit.

When drilling into concrete, ensure a minimum hole depth of 30mm.

 Reposition the oven back into the anti-tilt plate, aligning the stability bolt bracket with the 10mm drilled

hole. Slide the bolt through the bracket into the hole.

 Slide the oven back into the anti-tilt plate until there is a 2cm gap between the rear of the oven and the

wall.

 Check the height and level of the oven. If required, pull the oven back out and adjust the leveling feet.

 Connect the electricity supply but do not turn on until installation is complete.

NOTE: Only a qualified person should install the appliance, according to the instructions provided. The

manufacturer and supplier deny all responsibility for improper installation, which may cause harm to people and

animals and damage to property. The power supply must be disconnected before any adjustments or

maintenance work is done on the appliance.
