1. Pull out spring split pin [A] of safety bolt [11] and fold xing [B] in the opposite direction
with the maximum angle in order to pull the safety bolt out of square tube [7].
2. Loosen safety screw [6] on the tube clamp of main tube [3] and crank square tube [7] all
the way down with crank [8]. Fix the position of the square tube with safety screw [6].
3. Pull out spring split pin [A] of safety bolt [12] and fold xing [B] in the opposite direction
with the maximum angle to pull the safety bolt out of upper extension tube [5].
4. Loosen safety screw [4] on the tube clamp of square tube [7] and crank upper extension
tube [5] all the way down with crank [8]. Fix the position of the extension tube with
safety screw [4].
5. Remove the spotlights. During disassembly, pay attention to an even weight distribution
to reach a centric load of the stand.
6. Loosen the safety screw of the mount and detach the truss beam.
7. Pull out spring split pin [A] of safety bolt [10] and fold xing [B] in the opposite direction
with the maximum angle to pull the safety bolt out of main tube [3].
8. Loosen safety screw [1] on the lower carriage, to which the four cross struts are attached,
and fold up the feet of stand [2].
9. Pack the individual parts of the system in their original packaging if possible, and store
the package in a dry place protected against moisture.
Disassembly
Operation
16
Wind Up 100-4
Lighting Stand
