User’s Guide OctaMic II © RME

25

Word Clock

 BNC, not terminated (6.3 kOhm)

 Switch for internal termination 75 Ohm

 Automatic Double/Quad Speed detection and internal conversion to Single Speed

 SteadyClock guarantees super low jitter synchronization even in varispeed operation

 Not affected by DC-offsets within the network

 Signal Adaptation Circuit: signal refresh through auto-center and hysteresis

 Level range: 1.2 Vpp – 5.6 Vpp

 Lock Range: 27 kHz – 200 kHz

 Jitter suppression: > 50 dB (> 130 Hz)

13.3 Digital Outputs

AES/EBU

 4 x, transformer-balanced, galvanically isolated, according to AES3-1992

 Output voltage Professional 4.0 Vpp

 Format Professional according to AES3-1992 Amendment 4

 Output voltage Consumer 2.0 Vpp

 Format Consumer (SPDIF) according to IEC 60958

 Single Wire: 4 x 2 channels 24 bit, up to 192 kHz

ADAT

 2 x TOSLINK

 Standard: 8 channels 24 bit, up to 48 kHz

 S/MUX: 16 channels 24 bit / 48 kHz, equalling 8 channels 24 bit 96 kHz

13.4 Digital

 Clocks: Internal, AES In, word clock In

 Jitter suppression of external clocks: > 50 dB (> 130 Hz)

 Effective clock jitter influence on AD-conversion: near zero

 PLL ensures zero dropout, even at more than 100 ns jitter

 Supported sample rates: 28 kHz up to 200 kHz

13.5 General

 Power supply: Internal switching PSU, 100 - 240 V AC, 30 Watts

 Idle power consumption: 10 Watts

 Typical power consumption: 14 Watts

 Dimensions including rack ears (WxHxD): 483 x 88 x 242 mm (19" x 3.46" x 9.5")

 Dimensions without rack ears/handles (WxHxD): 436 x 88 x 235 mm (17.2" x 3.46" x 9.3")

 Weight: 3.08 kg ( 6.8 lbs)

 Temperature range: +5° up to +50° Celsius (41° F up to 122°F)

 Relative humidity: < 75%, non condensing
