06
INSTALLATION
06
PRODUCT
There is a Picatinny compatible scope mount installed on the
Strom. Please follow the schematic below for proper installation.
Before attempting to install your Storm, please ensure that your
firearm is unloaded and the muzzle is pointed in a safe direction.
Unlock the mount. To do this,
depress the lock button and swing
the lever 180° to the open position.
Install the assembly onto the rail
and move the lever to the locked
position.
Check the tension to close. The
correct amount of tension is the
maximum amount you apply with
one hand to move the lever to a
closed position.
To adjust the tension, move the
lever to the open position and push
the lever towards the base. This will
make the adjustment nut protrude
on the opposite side of the base.
With the nut protruding, turn it to
the left or right to make the
necessary adjustment. This
process may take a few tries to get
it where you want it.
Open Position
Lock Button
Lever
Adjustment Nut
