Rinnai 10 Portable Room AC OIM
INTRODUCTION
This portable air conditioner can alter the room temperature and humidity. It has multiple functions of cooling
dehumidifying (drying) and fan ventilation and can be moved from room to room and transported from building to
building easily.
The air conditioner can maintain set room indoor air temperatures between 16°C and 32°C. The set room
temperature is displayed on the remote control and in the control panel on the unit. This does not mean that the air
conditioner will necessarily reduce the actual room temperature to the set room temperature.
•
Do not place the air conditioner or plastic window slider in direct sunlight. Close all curtains in the room being
cooled.
•
For maximum cooling (COOLING MODE), set the temperature at 18°C and the fan at HIGH. After
approximately 3 minutes, the compressor will turn on and cooled air will come out of the front air outlet.
Warm air will also come out of the rear outlet and into the exhaust hose.
•
In COOLING MODE the air conditioner will not cool unless the set temperature is below the existing room
temperature.
•
In COOLING MODE once the existing room temperature reaches the set temperature, the fan continues
operating and the compressor switches on and o to maintain the set temperature within the room.
•
For maximum cooling output keep the exhaust hose as short and as straight as possible. Minimise bends
which can reduce the maximum cooling capacity of the air conditioner. Elevate the air conditioner if necessary.
•
Make sure the air intake and outlet grills are unobstructed.
•
Clean the lters at least once every two weeks.
SPECIFICATIONS
MODEL RPC41MCWF
Function Cooling Only
Control Remote and Wi-Fi via App
Power Supply 220V-240V~ / 50Hz
Maximum Input Power 1700W
Maximum Input Current 8.5A
Dimensions - Net (H x W x D) 802mm x 493mm x 415mm
Dimensions - Packing (H x W x D) 885mm x 570mm x 515mm
Weight 36.5kg
Nominal Cooling Capacity 4.1kW
Rated Input Current 6.8A
Rated Input Power 1640W
Refrigerant Type R290
Refrigerant Volume 240g
Noise Level 64dB(A)
SPECIFICATIONS
