Rinnai 6 Portable Room AC OIM
APPLIANCE COMPONENTS
1. Control panel 2. Cool air outlet
3. Receiver window 4. Remote control (Refer separate Remote Control
Manual)
5. Exhaust outlet 6. Carry handles
7. Drain outlet 1 8. Drain outlet 2 (not used on this model)
9. Room air intake (lter located behind grill) 10. Lower air intake (lter located behind grill)
11. Swivel casters (x4) 12. Drain tray outlet
13. 1.2m exible 2 pin cord 220-240V 50Hz 10A 14. Adjustable window slide kit
15. Window exhaust duct window adaptor. 16. Exhaust duct (extends to 1.8M)
17. Duct to appliance adaptor 18. Wall exhaust adaptor
19. Wall exhaust terminal 20. Condensate drain hose
HIGH
MID
LOW
HEAT
DRY
FAN
COLL
TIMER
SLEEP
SWING
F
C
1
2
3
4
9
6
5
7
8
11
12
13
10
Front
Back
15
19
18 17 16
20
14
AIR CONDITIONER BASICS
