SERVICE MAINTENANCE SCHEDULE

Your ducted evaporative cooler should be serviced at two-year intervals after the date of installation by a qualied

licensed technician in accordance with the Schedule below. Failure to do so during the product warranty period

may void your warranty. This periodic service and maintenance will prolong the useful life of the unit, and help

keep it running safely and at optimum e󰀩ciency.

Date of Installation / / Installed By:

YEAR OF SERVICE 2 4 6 8 10 12

Service Date / / / / / / / / / / / /

Service Company / Technician

ELECTRICAL

Wiring

Fan Motor

Fan Motor Capacitor

Printed circuit boards

Water Pump

Inlet Solenoid

Damper Motor (if applic)

WATER DISTRIBUTION

Pump and associated ttings

Water distribution pipework

Water management system (if

applic)

Drain Valve

Water Supply Line

Bleed rate setting (if applic)

Water reservoir

Cooling pads

MAJOR COMPONENTS

Fan

Cabinet

CONTROLS

Wall control

GENERAL OPERATION

Pad saturation

Water level

Water ll

Water drain

Winter Seal (if applic)

GENERAL INSTALLATION-RELATED AND 3rd PARTY COMPONENTS (NOT BRIVIS PRODUCTS) *

Airow thru system

CONSUMABLES**

Fan Capacitor

Fan Collet

Snorkel

Hoses

O-rings

Pads (after fifth year)

Water level sensor

* Installation and other field-supplied components are not covered by Rinnai Product Warranty. These include, but are not limited to, control wiring, ducting,

diffuser, controls/thermostats, pipework and fabricated or added components and water and electrical connections to the appliance. These should be inspected as

they can affect the performance, reliability and safety of the cooler.

** Units contain consumable items that may require periodic replacement and are not covered by Brivis product warranty (e.g. lter pads, capacitors, hoses,

O-rings)

ACTION CODES

Inspected - Working Correctly - No Action Required

Adjusted Part Cleaned Part Replaced Part Repaired Part Referred to Installer

A C R RP RI
