External Attenuation
This oscilloscope allows you to set the external attenuation, supporting setting it in
log format.
display amplitude of the signal under test = actual amplitude of the signal under test
x probe ratio x attenuation ratio (not affect the actual amplitude of the signal)
Table 5.3 Range of the External Attenuation
Probe Ratio Max. Value Min. Value
≤ 1 100kX (10µ/Probe Ratio)X
> 1 (100k/Probe Ratio)X 10 µX
Skew
To avoid measurement result errors arising from the transmission delay of the probe
cable, the oscilloscope provides the probe delay adjustment. Click or tap the input
field of Skew to set the delay time of the probe with the pop-up numeric keypad. You
can also use the specified knob to set it. Its range is from -100.00 ns to 100.00 ns. The
default value is 0.00 s.
Bias
The oscilloscope provides the bias voltage adjustment function for active probes. This
function is used to adjust the signal under test that exceeds the input dynamic range
of the probe amplifier to an appropriate range to ensure the integrity of the signal
under test. When working with the RP7000/PVA7000 series probe, you need to click
or tap the input field of
Bias to set the bias voltage of the probe with the pop-up
numeric keypad.
Probe Information
After the oscilloscope recognizes the probe automatically, In the probe menu, you can
view information about the currently connected probe, such as the vendor, model,
serial number, and the last calibration time.
Go Back to the Vertical System Menu
In the
Probe setting menu, click or tap the Vertical menu to go back to the Vertical
system menu.
5.9 Amplitude Unit
Click or tap the channel status label at the bottom of the screen. Then the Vertical
system menu is displayed. Click or tap the drop-down button of Unit to select W, A, V,
or U. The default unit is V.
To Set the Vertical System
MHO2000 User Guide
54
