Attenuation (display amplitude of the signal: actual
amplitude of the signal under test)
10000X
15000X
20000X
50000X
10000:1
15000:1
20000:1
50000:1
When a current probe is connected to the oscilloscope, refer to
Amplitude Unit
to set
the amplitude unit to A. The following table lists the preset probe ratio of the
oscilloscope. You can also set a user-defined probe ratio according to your needs.
Table 5.2 Probe Ratio of the Current Probe
Menu
Attenuation (display amplitude of the signal: actual
amplitude of the signal under test)
0.001 V/A
0.002 V/A
0.003 V/A
0.005 V/A
0.01 V/A
0.02 V/A
0.03 V/A
0.05 V/A
0.1 V/A
0.2 V/A
0.3 V/A
0.5 V/A
1 V/A
2 V/A
3 V/A
5 V/A
10 V/A
0.001
0.002
0.003
0.005
0.01
0.02
0.03
0.05
0.1
0.2
0.3
0.5
1
2
3
5
10
To Set the Vertical System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
53
