• Peak Number: click or tap the input field of Peak Number and use the pop-up
numeric keypad to set the number of peaks. You can also use the specified knob
to set the value. The number of peaks ranges from 1 to 15. Its default value is 5.
• Threshold: click or tap the input field of Threshold to set the threshold of the
peak with the pop-up numeric keypad. You can also use the specified knob to
set it. The range of the threshold is related to the current FFT scale and offset.
• Excursion: click or tap the input field of
Excursion and use the pop-up numeric
keypad to set the excursion of the peak. You can also use the specified knob to
set it. The min. value of Excursion is 0. Its unit is consistent with that of FFT.
• Table Order: click or tap to select Amp Order or Freq Order as the sorting
mode under the Table Order menu. By default, it is "Amp Order".
Click or tap
Export, then the export setting interface is displayed. You can export the
peak search results to the internal memory or the external USB storage device in CSV
format. In the menu, click or tap the input field of
File Name to set the file name.
Click or tap the input field of File Path, and then the disk management menu (
Disk
Management
) is displayed. Select the desired location to export the file and then click
or tap
Export to export the peak search results.
Clicking or tapping the icon at the right side of Peak Search can close the the
peak search menu.
9.4 Logic Operation
In the Math menu, click or tap Operator to select the desired math operation. The
logic operations supported by this oscilloscope include A&&B, A||B, A^B, and !A.
After selecting the desired logic operation from the drop-down list of Operator, you
can configure its settings for the selected logic operation type.
Math Operation
MHO2000 User Guide
138
