Baud Rate
You can select the baud rate of data transmission (i.e. specifies a clock frequency).
Click or tap the drop-down button of Baud Rate, then select the preset baud rate.
The available baud rates include 50 bps, 75 bps, 110 bps, 134 bps, 150 bps, 300 bps,
and etc. You can also self-define the baud rate.
Data Bits
Indicate the number of bits per frame. Click or tap the drop-down button of Data Bits
to select the desired data bits. The available data bits include "5 Bits", "6 Bits", "7 Bits",
and "8 Bits".
Stop Bit
Indicates when to stop outputting data. Select the desired stop bit in the Stop Bit
item. The available data bits include 1 Bit, 1.5 Bits, and 2 Bits.
Parity
Used to check whether the data are properly transmitted. Select None, Even, or Odd
in the Parity item.
• None: indicates that no check bit appears during the transmission.
• Even: indicates that the total number of "1" in the data bit and check bit is an
even number. For example, when 0x55 (01010101) is sent, "0" should be added
to the check bit.
• Odd: indicates that the total number of "1" in the data bit and check bit is an
odd number. For example, when 0x55 (01010101) is sent, "1" should be added to
the check bit.
8.7.14 I2C Trigger
I2C is a 2-wire serial bus used to connect the microcontroller and its peripheral
device. It is a bus standard widely used in the microelectronic communication control
field.
The I2C serial bus consists of SCL and SDA. Its transmission rate is determined by SCL,
and its transmission data is determined by SDA, as shown in the figure below. The
instrument series triggers on the start condition, restart, stop, missing
acknowledgment, specific device address, or data value. Besides, it can also trigger on
the specific device address and data values at the same time.
To Trigger the Oscilloscope
MHO2000 User Guide
104
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
