Data Type
Sets the effective pattern of the data signal. It can be set to H (high level) or L (low
level).
Trigger Condition
Sets the Setup/Hold trigger condition in the When menu.
• Setup: the oscilloscope triggers when the setup time is smaller than the
specified setup time. Click or tap the input field of Setup to set the setup time
with the pop-up numeric keypad. You can also use the specified knob to set it.
• Hold: the oscilloscope triggers when the hold time is smaller than the specified
hold time. After selecting this type, click or tap the input field of
Hold to set the
hold time with the pop-up numeric keypad. You can also use the specified knob
to set it.
• Setup/Hold: the oscilloscope triggers when the setup time or hold time smaller
than the specified time value. After selecting this type, click or tap the input field
of Setup and Hold respectively to set the setup and hold time with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
values.
Level Selection and Setting
After the trigger condition setting is completed, you need to adjust the trigger level
to correctly trigger the signal and obtain a stable waveform.
Click or tap the input field of
SCL Level or SDA Level respectively to set SCL level and
SDA level with the pop-up numeric keypad. You can also use the specified
multifunction knob to adjust SCL level and SDA level or use the trigger level knob to
adjust the level (the focus of the trigger level knob is the last modified level). For
details, refer to descriptions in
Trigger Level
. The current trigger level is displayed in
the trigger information label at the top of the screen.
8.7.12 Nth Edge Trigger
Triggers on the Nth edge that appears after the specified idle time. For example, in
the waveform shown in the figure below, the instrument should trigger on the second
rising edge after the specified idle time (the time between two neighboring rising
edges), and the idle time should be within the range between P and M (P< Idle
Time<M). Wherein, M is the time between the first rising edge and its previous rising
edge; P is the maximum time between the rising edges that participate in counting.
To Trigger the Oscilloscope
MHO2000 User Guide
100
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
