Level Selection and Setting
After the trigger condition setting is completed, you need to adjust the trigger level
to correctly trigger the signal and obtain a stable waveform.
Click or tap the input field of Level A and that of Level B to set Level A an Level B
with the pop-up numeric keypad. You can also use the trigger level knob or use the
specified multifunction knob to adjust Level A and Level B respectively. Check the
checkbox of
Linkage to link Level A and Level B. The Level A and Level B will be
adjusted synchronously. The upper limit and lower limit values change at the same
time. The trigger level deviation (the difference between the upper limit and lower
limit of the trigger level) remains unchanged. For details, refer to descriptions in
Trigger Level
. The current trigger level is displayed in the trigger information label at
the top of the screen.
TIP
Press down the trigger level knob and rotate it to adjust Level A, Level B, and Level AB (when
linkage is enabled) in sequence.
8.7.9 Window Trigger
Window trigger provides a high trigger level and a low trigger level. The instrument
triggers when the input signal passes through the high trigger level or the low trigger
level.
Trigger Type
Click or tap the drop-down button of Type to select "Window" from the drop-down
list. Then set the parameters for Window trigger.
To Trigger the Oscilloscope
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
93
