can also fold the supporting legs when the instrument is not in use for easier storage
or shipment, as shown in the figure below.
Supporting Legs
（b）To fold the supporting legs
（a）To unfold the supporting legs
Figure 4.5 Adjust the Supporting Legs
4.4.2 To Connect to AC Power
The AC power requirements of the oscilloscope are 100-240 V, 50/60 Hz, 400VA Max.
Please use the power cord provided in the accessories to connect the oscilloscope to
the AC power source, as shown in the figure below.
Power Cord Connector
Figure 4.6 Connect to AC Power
WARNING
To avoid electric shock, ensure that the instrument is correctly grounded.
Quick Start
MHO2000 User Guide
14
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
