Label Knob Label Knob
Horizontal SCALE
Horizontal Scale
Knob
2
Multipurpose
Knob 2
Vertical POSITION
Vertical Position
Knob
LEVEL
Trigger Level Knob
Vertical SCALE
Vertical Scale
Knob
- -
Content Conventions in this Manual
DHO1000 series digital oscilloscope includes the following models. Unless otherwise
specified, this manual takes the 4-channel model DHO1104 as an example to illustrate
the basic operation methods of DHO1000 series.
Model Max. Analog Bandwidth Analog Channels
DHO1072 70 MHz 2
DHO1074 70 MHz 4
DHO1102 100 MHz 2
DHO1104 100 MHz 4
DHO1202 200 MHz 2
DHO1204 200 MHz 4
Document Overview
DHO1000 User Guide
10
