918-I Heavy Duty Roll Grooving Machine
12345678
ABCD T
Nom. Tubing Outside Gasket Groove Groove Nominal Min. Max.
Size Diameter O.D. Seal Width Dia. Groove Allow. Allow.
Inches A +.03 +.00 Depth Wall Flare
Basic Tolerance +.03 –.00 –.02 (1) Thick. Dia.
–.00
2 2.125 ±0.002 0.610 0.300 2.029 0.048 0.064 2.220
2
1
/
2
2.625 ±0.002 0.610 0.300 2.525 0.050 0.065 2.720
3 3.125 ±0.002 0.610 0.300 3.025 0.050 0.045 3.220
4 4.125 ±0.002 0.610 0.300 4.019 0.053 0.058 4.220
5 5.125 ±0.002 0.610 0.300 5.019 0.053 0.072 5.220
6 6.125 ±0.002 0.610 0.300 5.999 0.063 0.083 6.220
Table IV. Copper Roll Groove Specifications
(1) Nominal groove depth is provided for reference only. Do not use groove depth to determine acceptability of groove.
Table III. Troubleshooting (cont.)
PROBLEM CAUSE CORRECTION
Pipe raises or tends to
tip groover over back-
wards.
Pump not delivering oil,
cylinder does not
advance.
Pump handle operates
with “spongy” action.
Cylinder extends only
partially.
Not level.
Pump release valve open.
Low oil in reservoir.
Dirt in pump body.
Seats worn or not seating.
Too much oil in reservoir.
Air trapped in system.
Too much oil in reservoir.
Pump reservoir is low on oil.
Depth adjustment set incorrectly.
Adjust stands to level pipe.
Close release valve.
Check oil level per instructions.
Have serviced by qualified technician.
Have serviced by qualified technician.
Check oil level per instructions.
Position ram lower than pump by tipping the ma-
chine on its side opposite the operator. Extend
and return the cylinder piston several times to per-
mit air to return to the pump reservoir.
Check oil level per instructions.
Fill and bleed system.
Follow depth adjustment instructions.
