918-I Heavy Duty Roll Grooving Machine
Table I. Standard Roll Groove Specifications
(1)
NOTE! All Dimensions are in Inches.
T AB C D
NOM. PIPE MIN. GASKET GROOVE GROOVE NOM.
PIPE DIAMETER WALL SEAT WIDTH DIAMETER GROOVE
SIZE O.D. TOL. THK. +.015/-.030 +.030/-.015 O.D. TOL. DEPTH (Ref.) (2)
1 1.315 +.013 .065 .625 .281 1.190 +.000 .063
-.013 -.015
1
1
/
4
1.660 +.016 .065 .625 .281 1.535 +.000 .063
-.016 -.015
1
1
/
2
1.900 +.016 .065 .625 .281 1.775 +.000 .063
-.016 -.015
2 2.375 +.024 .065 .625 .344 2.250 +.000 .063
-.016 -.015
2
1
/
2
2.875 +.029 .083 .625 .344 2.720 +.000 .078
-.016 -.015
3 3.50 +.030 .083 .625 .344 3.344 +.000 .078
-.018 -.015
3
1
/
2
4.00 +.030 .083 .625 .344 3.834 +.000 .083
-.018 -.015
4 4.50 +.035 .083 .625 .344 4.334 +.000 .083
.020 -.015
5 5.563 +.056 .109 .625 .344 5.395 +.000 .084
.022 -.015
6 6.625 +.050 .109 .625 .344 6.455 +.000 .085
-.024 -.015
8 8.625 +.050 .109 .750 .469 8.441 +.000 .092
-.024 -.020
10 10.75 +.060 .134 .750 .469 10.562 +.000 .094
-.025 -.025
12 12.75 +.060 .156 .750 .469 12.531 +.000 .110
-.025 -.025
Table II. Pipe Maximum and Minimum Wall Thickness
NOTE! All Dimensions are in Inches.
CARBON STEEL OR STAINLESS STEEL
ALUMINUM PIPE OR TUBE PIPE OR TUBE PVC PIPE
Pipe Size Wall Thickness Wall Thickness Wall Thickness
Min. Max. Min. Max. Min. Max.
1" .065 .133 .065 .109 .133 .133
1
1
/
4
" .065 .140 .065 .140 .140 .140
1
1
/
2
" .065 .145 .065 .145 .145 .200
2" .065 .154 .065 .154 .154 .154
2
1
/
2
" .083 .203 .083 .188 .203 .276
3" .083 .216 .083 .188 .216 .300
3
1
/
2
" .083 .226 .083 .188 .226 .318
4" .083 .237 .083 .188 .237 .337
5" .109 .258 .109 .188 .258 .258
6" .109 .280 .109 .188 .280 .280
8" .109 .322 .109 .188 .322 .322
10" .134 .165 .134 .188 ——
12" .156 .180 .156 .188 ——
(1) As per AWWA C606-87
(2) Nominal Groove Depth is provided as a reference dimension only. Do not use groove depth to determine acceptability of a groove.
CAUTION: Do not use to groove 8" schedule 40 steel pipe that is harder than 150 BHN. Attempting to groove this harder pipe may result in
improperly formed grooves that do not meet required specifications.
NOTE! Fitting manufacturer's recommendations should be followed regarding maximum allowable flare diameters.
