9

ASSEMBLING CHARGING STAND

01

Remove all parts from the box and find

the charging dock, base, accessory

holder, and metal connecting pipe.

You will need to use a screwdriver to

secure screws.

Note: Screws are included and

attached to the charging base.

02

Place the base on the floor and insert

the metal connecting pipe. Place screw

into the connection point and fasten

together with a screwdriver (Figure 1.1).

Note: Make sure the metal

connecting pipe is placed in the

correct direction. The side with

the ridges should face the back.

03

Attach the accessory holder to the

metal connecting pipe by sliding on

from the top (Figure 1.2).

Optional: The accessory holder

can also be placed on metal

connecting pipe by using both

hands to push it into the stand.

04

Connect the charging dock to the

metal connecting pipe. Place the screw

into the connection point and fasten

together with a screwdriver.

Charging Stand

Figure 1.1

Figure 1.2

Figure 1.3

Front

Back
