Introduction

The Fono Mini A2D MK2 is designed to amplify the signal from a moving magnet cartridge to a suitable level for all line level inputs of an audio

amplier. The USB interface also offers the ability to simply transfer vinyl to PC. The Fono Mini A2D MK2 amplier offers exceptional performance

and convenience and will be a valuable addition to any hi- set up.

Rear panel connectivity

1. Earth Terminal

2. Input Connections - Connect the signal lead (tonearm leads) to the input sockets labelled on the rear panel. If the tonearm requires a separate

earth, please connect the earth lead to the earth terminal located on the rear panel of the Fono Mini A2D (1).

N.B. Only undo the earth screw just enough to t your earth lead.

3. Output Connections - Connect the output sockets of the Fono Mini A2D to a suitable ‘line level’ input on your amplier using appropriate RCA

leads. Do not connect to an amplier’s integrated ‘Phono’ or ‘Disk’ input.

4. Power Connection - Connect the designated power supply to the power socket situated on the rear panel. Power on is indicated by illumination of

the red LED (5).

Set-up is now complete. Simply switch on, sit back and enjoy!

Connections via USB to PC

To transfer vinyl to your PC, you will need to install a digital audio editor. Such software is widely available as a free download (such as Audacity).

This is a simple interface which allows monitoring of volume and balance whilst transferring your audio to your PC hard drive.

Audio editing software includes a level meter which indicates the output level achieved when playing a piece of vinyl. You should adjust the output as

necessary via the ‘Level’ control located on the front panel. Always take special note of record levels to ensure optimum recording quality.

2 3 4
