ASSEMBLY AND SET-UP
5
2 Slide axle through fork, spacer and wheel hub. When axle passes through
the other side of the wheel hub, add the other spacer, and slide though the
fork. Secure with washer and nut.
Note: Front axle is installed with the spacer between the fork and wheel.
1 Position wheel in front fork and
slide disc brake into caliper.
3 With a 17mm and 19mm wrench,
tighten the front wheel.
WARNING: Failing to
properly adjust and tighten the nuts
and bolts that affix the fork can
cause you to lose control and fall.
Installing the Front Wheel
Required Tools: 17 mm Wrench and 19 mm Wrench
Inflating the Tires
Tires are inflated when shipped, but they invariably lose some pressure between the point of manufacturing and
your purchase. Inflate the tires to the correct PSI before first time use.
Lower air pressure can result in a shorter ride time. Periodically check tires. Reinflate when needed.
Axle Blot
Fork
Fork
Spacer
Spacer
Washer
Brake Caliper
Washer
Nut
Nut
WARNING:
Do not use the electric product for
the first time until you have inflated
the tires to the correct PSI. Failure
to do so may damage your motor
bike and void your warranty.
WARNING:
Do not over inflate, as this could
damage tire or wheel.
Note: The pressurized air supplies
found at gasoline stations are
designed to inflate high-volume
automobile tires. If you decide to
use such an air supply to inflate your
motor bike tires, first make sure the
pressure gauge is working, then
use very short bursts to inflate to
the correct PSI. If you inadvertently
over-inflate the tire, release the
excess pressure immediately.
1 Using a bicycle-style tire pump equipped for a Schrader-type valve, inflate
the front tire to the correct PSI indicated on the sidewall of the tire.
