ASSEMBLY AND SET-UP
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
Attaching the Handlebars
Required Tools: 5 mm Allen Wrench and 6 mm Allen Wrench
Attaching the Rear Number Plate
Required Tool: 4 mm Allen Wrench
Attaching the Front Number Plate
1 Place the handlebars in the
handlebar clamps.
Note: Handlebar clamps are located
in the plastic bag with tools
and manual.
1 Attach the number plate to the
rear of the frame by using the 4 mm
Allen wrench to tighten the two (2)
bolts as shown above.
1 Slip the cables through the slit on
the top of the number plate. Align the
number plate with the holes on the
fork and snap on the number plate.
2 Align parallel to the fork and
tighten the bolts using a 6 mm Allen
wrench. When properly tightened,
the handlebars should not move
forward or backward.
3 Adjust the brake lever adjuster to
the proper place and tighten it with
the 5 mm Allen wrench.
WARNING: Failing to
properly adjust and tighten the bolts
that affix the handlebars can cause
you to lose control and crash.
