BEFORE YOU BEGIN
3
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during
shipping. Because the motor bike was 95 percent assembled and packed at the factory, there should not be any
problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult with experience in bicycle mechanics.
Allow up to 30 minutes for assembly, not including initial charge time.
Allow up to 12 hours for charge (see page 7 for charging information).
Required Tools
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR RAZOR
ELECTRIC MOTOR BIKE. The
motor bike has been built to
certain Razor design specifications.
The original equi pment supplied
at the time of sale was selected
on the basis of its compatibility
with the frame, fork and all other
parts. Certain aftermarket products
may not be compatible and will void
the warranty.
Charger
(Note: Charger design may vary from
one shown)
4 mm, 5 mm and 6 mm
Allen Wrenches
10 mm, 17 mm and 19 mm
Wrenches
Phillips Screwdriver
3.
Product ID Locations:
(See locations to the left)
1. Battery cover
2. Frame (underneath unit)
3. Charger
4. Box - side of UPC (not shown)
Plastic Bag Contents:
• Charger
• Handlebar Clamps
• Front Number Plate
• Front Axle Bolt
• Tools
• Owner’s Manual
Throttle
Power Switch
Charging Port
Drive
Chain
Front Fork
Parent Controlled
HIGH/LOW
Speed Switch
Front and Rear
Brake Levers
1.
2.
