RaySafe X2 – CT
P is the measured pressure, T
std
= 293.15 K (20
°
C) and P
std
= 101.325 kPa.
Tip! The temperature and pressure sensors are located inside the CT sensor. Their measured val-
ues can be viewed by importing the measurement session to RaySafe View and exporting to Excel.
CT SENSOR: SPECIFICATIONS
Dimensions: 14 × 22 × 219 mm (0.5 × 0.9 × 8.6 in)
Diameter: 12.5 mm (0.5 in)
Weight: 86 g (3.0 oz)
Storage temperature: -25 – +70
°
C (-13 – +158
°
F)
Storage humidity: Non-condensing
Operating temperature: 15 – 35
°
C (59 – 95
°
F)
Operating atmospheric
pressure:
55 – 110 kPa (5000 m above sea level)
Operating humidity: < 80 % relative humidity, non-condensing
Effective length: 100 mm (3.94 in), indicated by the two white lines on the
sensor
Direction of incident radiation: ± 180
°
The combined standard uncertainty for a dose or dose rate measurement is calculated according
to the method described in IEC 61674:2012, annex A. The calculation considers, among others,
the influence quantities repeatability, radiation quality, direction of incident radiation, pressure and
temperature and is based on the calibration uncertainty of the RaySafe calibration lab as well as
data from PTB type testing. The combined uncertainty is less than 5 %.
SETTING: UNITS
Select displayed unit for dose and dose rate.
1 Gy = 114.1 R
Note! X2 systems subject to legal calibration (Eichung) in Germany or Austria do not have the
possibility to change dose unit to R¨ontgen (R).
SETTING: STOP DELAY
The stop delay setting defines for how long the instrument will wait for more radiation to include
in the same measurement.
Use a longer stop delay when using a phantom and a slow rotation rate, to prevent that an axial
scan will be cut into two measurements.
33
