INSTALLATION
Check the appliance is electrically safe and gas sound when you have nished.
½" G conical
(ISO 7-1) male
½" G cylindrical
(ISO 228-1) male
BA C
½" G cylindrical
(ISO 228-1) female
Fig. 6.1
Fig. 6.2
Connection to the Gas Supply
Gas connection (GB) Cat: II
2H3+
The tting (Fig. 6.1) is made up of:
• Nut “C”
• Elbow fitting “B”
• Gasket “A”
n
Be careful when exible pipes are used that they do
not come into contact with moving parts.
n
IMPORTANT! Do not use a naked ame to test for
leaks.
To maintain the thickness of 30 mm, the hob is tted with a
channel to contain the connection pipe.
The gas inlet union can be turned in the direction required
after the elbow tting “B” and nut “C” connection (Fig. 6.1)
has been slackened (Fig. 6.2) .
n
Never put the gas inlet in a downward position.
n
Never attempt to turn the elbow “B” without having
rst slackened o the relative lock nut “C”.
The gasket “A” (Fig. 6.1) guarantees the seal of the gas
connection. It is recommended that it be replaced whenever
it shows even the slightest deformation or imperfection.
