WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON
Disconnect from electricity and gas before servicing. Check appliance is safe when you have nished.
13
J
Auxiliary,
Semi-Rapid
and Rapid
burners
J
Triple Ring
burner
Check in the ‘Technical Data’ section at the back of the
instructions that the hob is convertible to the gas you want
to use.
n
This conversion must be performed by a suitably
competent person, in accordance with these
instructions and with the local supply company
requirements.
n
Failure to convert the appliance correctly could
invalidate any warranty or liability claims and lead
to prosecution.
n
The conversion instructions must be used in
conjunction with the rest of the appliance
instruction, in particular for information on
Standards, cooker positioning, connection, hose
suitability, etc.
n
When servicing or replacing gas-carrying
components, disconnect from the gas before
starting, and check that the appliance is gas sound
after completion.
n
Do not use reconditioned or unauthorised gas
controls.
n
Disconnect from the electricity supply before
commencing servicing.
n
Before electrical reconnection, check that the
appliance is electrically safe.
Injectors
To replace the injectors proceed as follows:
1. Remove the pan supports, the burner and caps.
2. Using a socket spannner unscrew “J” (Fig. 6.1) and (Fig.
6.2).
3. Choose the injectors to be replaced according to
the data in the “Technical Data” chapter. The injector
diameter, expressed in hundredths of a millimetre, is
marked on the injector body.
Fig. 6.1
Fig. 6.2
6. Conversion to LPG
